20KHz/35KHz/40KHz Ultrasonic Welding Machine Generator Manufacturers (Germany Circuit)

Product Overview

Description

20KHz/35KHz/40KHz Ultrasonic Welding Machine generator Manufacturers (Germany Circuit)

1) Germany automatic tuning system,PLL lock technology
2) Self diagnose and display.
3) Five-step amplitude adjustable (60-100% in 10% steps)
4) Control  time accuracy up to 0.001 seconds.
5) Weld Mode:Time mode
6) Adoption of the internal signal output/direct and automatic matching of mechanical systems.

7) Department of mechanical combination output, convenient automatic match.
8) The original German (PINOT) automatic constant amplitude

9) The complete machine adopts fittings: original imported Germany transducer and vibration board ,PLC (Japan PANASONIC), Taiwan human-machine interface



Feature	Value
Input Voltage	220-240 V AC
Size	H 320x W 140 x L 420
Weight	13 kg
Display	Touch Screen
Auto Tuning	Real Time
Nominal Output Power	1000,1500,2000 & 3000 W / 20 kHz
Nominal Output Power	400,600&900W/35KHz-40KHz
Maximum Output Power	10 % above Nominal Power
Constant Amplitude	205 - 265 V AC
Amplitude	60 - 100 % in 10 % steps
Time Mode	0.001-9.999s
US Stop Mode	Integrated
24V Supply	Integrated 800 mA short circuit protected
Inputs	opto couplers 20 - 28 V DC / 7 mA
Outputs	opto couplers 22- 28 V DC / max. 250 mA
Emergency Stop	Message in Display
Error Message Display	Text Message
Interface for PLC	Integrated
Ambiente Temperature	0 - 50 ℃





Standard and Germany Computerised system we offered ,More information welcome to contact with us !
