HONEYCOMB CORE SPECIFICATION
Cell size | 8mm | 10mm | 12mm | Tolerances |
Depth(thickness) | 5~350mm | ±19.7mil(0.5mm) | ||
Max sheet length | 2440x1220mm | ±118mil(3.0mm) | ||
Max sheet width | ||||
Density kg/ m3 | 80 | 75 | 70 | 20% |
Wall thickness | 19.7mil(0.5mm) | 20% | ||
Compressive strength | 1.5-2 Mpa |
| ||
Shear strength | 0.5 Mpa | |||
Temperature range | From-15 to+ 80celsius | |||
Thermal conductivity w/mk 0° | 0.01 | |||
Water absorption max | 0.1 | |||
Water absorption 24H | 0.1 | |||
flammability | normal | |||
Sound reduction Factor 50-4.000Hz | 22db | |||
Color | White/Milky white | |||
Advantages:
• Weight savings.
• High Strength to weight and stiffness to weight ratios.
• Cost savings in handling and shipping.
• Ease of handling.
• Fuel economy and increased speed in transportati.
Applications:Marine/Transportation/furniture/construction etc.
![]() | ![]() |
Properties
* 1) strong: compress strength 2Mpa
* 2) light: common density is 80 Kg per cubic meter (could make to client order)
*3) different cell size: common diameter is 8mm and 10mm, special demand could discuss
size: 1220*2440mm or 1150*2300mm, Max 1200*4000mm, Max width 1500mm
thickness: 5mm-60mm, special size discuss
*4) surface non woven: 30/40/60 g per sqm could choose
* 5) Waterproof
* 6) Corrosion Resisting
* 7) Anti-vibrant
*8) Anti-aging / Durable
* 9) Convenient / Flexible Installation
*10) non toxic, Environmental Protection, recyclable
*11) Easy to process: Insert parts, pre-cut hole & window etc

Applications
♠ structural core material for sandwich panels
♠ core material in van wall, dry container boxes,truckbody, under floor for noisy reducting
♠ in pools building and its around ground surface and cover
♠ as inserts material for door for furniture for twin wall etc.
♠ it is a good material in boat building for yacht for big ship in its cabin, uper instruction etc.
♠ boxes of water for holding water
♠ packing material,light weight and better protection for cargoes
PP honeycombcore without surface the cell is open
1. Sample: How could I get a sample?
Sample is free of charge but the air express fee is usually borne by customer;
New sample fee is USD200 .
Note: we will return back sample fee since you place the order in the future.
2. Price: Could I get your company product price list?
Sure, please kindly tell us your requested details, such as thickness, size of the core, raw materials request, end application etc. Later we will offer you quotation at the first time.
3. Payment Terms: How do we arrange payment?
T/T:Telegraphic Transfer (wire transfer), 50% down payment, balance upon before shipment or against copy bill of lading;
4. Lead Time: How soon we can get the shipment?
We will arrange production since the order and payment are confirmed, we will take 7-15 days to arrange production and book shipping space in advance before goods is ready.
