Fiberglass/ Wool glass Ceiling / Acoustic Ceiling / False ceiling

Product Overview

Description

Fiberglass Acoustic Ceiling



The fiberglass acoustic ceilings and panels are usually used in partions of interior walls and interior roof,wich can effectively block off the noises interior and ouside,achieves the thermal insulation.





Technical Data:

Material: Torrefaction Compounded high density fiberglass wool

Face: Special painting laminated with decorative fiberglass tissue

Color: white, black and others to order

Fire-resistant: class A, non combustible

NRC: 0.9-1.0, excellent sound absorption

Thermal-resistant: >0.4 (m2k/w)

Humidity: Dimensionally stable with RH up to 95% at  40c, no sagging, wrapping, or delaminating

Moisture rete: <1% (JC/T670-2005)

Enviromental impact: Tiles and packing are fully recyclable



Main Application Areas: (SQUARE)

The titles are manufactured from high density dry felf resin bonded fiberglass wool, with fine texture painted glass tissue facer,plain tissue backer and sealed and painted edges.square edge titles will be paralled to suspension system after installation.





Main Application Areas: (TEGURLAR)

The titles are manufactured from high density dry felf resin bonded fiberglass wool, with fine texture painted glass tissue facer,plain tissue backer and sealed and painted edges,the four edges have grooves being tegular shape and sealed, the titles will be lower than the suspension system after installation, mainly used in shopping malls and stadium,conference rooms and libraries as well as offices.



Main Application Areas: (concealed A )

The titles are manufactured from high density dry felf resin bonded fiberglass wool, with fine texture painted glass tissue facer,plain tissue backer and sealed and painted edges.The edges of two are are square ,while others are concealed, the titles will cover the suspension system after installation, they are easy to trim and install.





Main Application Areas: (concealed B )

The titles are manufactured from high density dry felf resin bonded fiberglass wool, with fine texture painted glass tissue facer,plain tissue backer and sealed and painted edges.The edges of two are square, while others are concealed ,the tiles will cover the suspension system after installation, but this type of titles can not be trimed and re-installed compared with Concealed A



Main Application Areas: (concealed C )

The titles are manufactured from high density dry felf resin bonded fiberglass wool, with fine texture painted glass tissue facer,plain tissue backer and sealed and painted edges.The four edges have grooves,it can be sticked directly to the ceiling without suspension system,The tiles are suitable for low flap ceiling space and concrete-made,wooden-made or gypsum-made ceilings





Installation Instructions:

Using exposed T-Grid system and Plane T-Grid system with width :15mm / 24mm.

Demountable

Both Metric and British Systems T-Grids are available





Packages and Specifications:

Size (mm)	Thickness ( mm)	Packing (pcs/ ctn)	Kgs/m2
600x600	15	20	1.8
600x1200	20	15	2.3
600x1800	20	10	2.76
1200x1200	25	10	3.48
