Product Overview
Description
Technical Data:
Model NO. | JC-L-220-1 | JC-L-220-2 | JC-L-110-1 | JC-L-110-2 | ||||
Working Volt | 220V | 220V | 110V | 110V | ||||
Power | 1KW | 2KW | 1KW | 2KW | ||||
Specifications | 210*165*350mm | |||||||
Adjustable temperature | 0°C——1200°C | |||||||
Heating rate (from 0°C to 1200°C) | 35mins | 25mins | 35mins | 25mins | ||||
Accuracy | ±1°C
| |||||||
Display mode | Adopting AI PID control method; Measured values (PV), set data (SV) can be shown at the same time; Set data can be changed by arrow buttons | |||||||
Material of the furnace liner | Ceramic fiber insulation materials | |||||||
Material of the furnace cover | Stainless Steel | |||||||
Note | With thermocouple input, relay output | |||||||
Model NO. | JC-K-220-1 | JC-K-220-2 | JC-K-110-1 | JC-K-110-2 | ||||
Working Volt | 220V | 220V | 110V | 110V | ||||
Power | 1KW | 2KW | 1KW | 2KW | ||||
Heating rate(from 0°C to 1200°C) | 35mins | 25mins | 35mins | 25mins | ||||
Adjustable temperature | 0°C——1200C | |||||||
Specifications | 210*165*350mm | |||||||
Size of the chamber | 70*70*145(circle) | |||||||
Capacity | 1——3kg | |||||||
Weight | 5kg | |||||||
Accuracy | ±1C | |||||||
Display mode | Adopting AI PID control method; Measured values (PV), set data (SV) can be shown at the same time; Set data can be changed by arrow buttons | |||||||
Material of the furnace liner | Ceramic fiber insulation materials | |||||||
Material of the furnace cover | Stainless Steel | |||||||
Material of the crucible | Graphite | |||||||
Note | With thermocouple input, relay output | |||||||
Provide | Each furnace will be equipped with a 1kg capacity crucible and a tong. | |||||||
Features
1,Exquisite & Convenient:
Small size, light weight, can be operated independently.
2,Operated simply:
The parameters can be changed convenient by pressing arrow buttons.
The seting temperature and surveyed temperature can be showed at the same time.
Working reliably
3,Controlled precise:
Microprocessor PID control, PID auto-tuning function ensure the accuracy of the temperature control in any state
4,Working efficient:
Melt fast, efficiency highly, good insulation effect, low power consumption.
5,safety&environmental protection
Automatic, intellective, have not special requirement about working condition.
Noiseless, no radiation.
Applications:
1, Jewelry processing industry of gold, silver, copper and other metals smelting.
2, Schools, laboratories, chemical smelting . Melting and heat treatment of non-flammable, non-explosive materials.
3, Melting and heat treatment of products which need highly temperature accuracy and reliability.
4, Small temperature processing applications.
