0.10mm (DigiDot HND) Polyester base image setting film

Product Overview

Description

0.10mm (DigiDot HND) Polyester base image setting film





 Image Setting Film Description:

* Spectral sensitivity: HeNe-laser and extended red laser diode(630-670 nm)



*Emulsion coated on a 0.10mm(DigiDot HND) polyester base



Image setting Film Features
> Perfect" hard dot" edge sharpness and practical density even in the small dots
> Wide System latitude: wide processing and exposure latitude
> Low dot shift in plate copy
> Good batch-to-batch consistency
> Convenience and ease of use because of available ECO equipment
> Low chemistry consumption
> Linear output for conventional screening & stochastic screening
> Anti-static before and after processing
> Open system: processable in all RA and HD chemistries



Satelight conditions: Dark green light.

Storage: The films are preferably stored in a cool dry place temperature below 20°C

(68°F) and a relative humidity between 30% and 60%.



Applicable models:

Brand name	Model of machine	Light source
SCREEN	FT-R3020/5055	633nm/650nm
Fuji's Luxel	9000/6000	650nm
ECRM	VRL series&Mako	670nm
Creo	Dolev450/800v/800v2	632.8nm
Heidelberg	Signasetter Pro	632.8nm
	Herkules Pro	670nm
	ULTRE5800	670nm
AGFA	SelectSet Avantra series	650nm
Panther	Panther Pro46	670nm
Cron	ACF series	650nm
Eastcom	DX series	650nm
