Thermosetting polyester Ral7032 texture powder coating for metal turniture

Product Overview

Description

Detailed Product Description



Polyester Powder Coating
1.Outstanding durability
2.UV resistance properties
3.Good resistance to discoloration and yellowing

Products series

• Available in standard curing and lower temperature curing


• Available in multi-colors, different gloss level such as high gloss ( above 90°), flat gloss( 70-80°), semi gloss ( 10-60°), matt( below 10°), particular color and gloss is made according to customers’ requirements.


• Available in various kinds of art textures, such as sandy, wrinkle, lanose grain, hammer tone, metallic effect etc.



Physical property

Specific gravity: 1.4~1.8g/cm³ (varied with different color and gloss)

Particle size: average 10~38um, proportion 10~84um > 90%, it can be adjusted if special requirement is put forward to us in advance.



Curing temperature

Standard type: 190°c/15 minutes

Or 160°c/20 minutes, 200°c/10 minutes if customer require



Pre-treatment

The overall quality of the coating system is largely dependent on the type and quality of the pre-treatment. The recommended types of pre-treatment for the most frequently used substrates are:



Aluminium	Chromate conversion
Steel	Zinc phosphate
Zinc coated steel	Zinc phosphate or chromate conversion



Coating method

Electrostatic spray gun

Tribo gun

Electrostatic Fluidized bed

Fluidized bed



Film performance



Test Item	Test standard and Method		Test index
Impact resistance	GB/T 1732 -1993	ISO6272	50kg·cm
Adhension(cross-cut)	GB/T 9286 - 1998	ISO2409	Class 0
Flexibility	GB/T 6742-1986	ISO1519	2mm
Pencil hardness	GB/T 6739-1996	ISO2815	1H-2H
Cupping test	GB/T 9753-1988	ISO1520	6mm
Salt spray resistance	GB/T 1771-1991	ISO7253	>400 Hours
Heat & humidity resistance	GB/T 1740-1979	ISO6270	>500 Hours,film gloss slightly lose
Note: 1. Above test are using 0.30mm thickness degreased, rust removed cold rolling steel plate, film thickness is 60-80um. 2. Film performance may slightly decrease with gloss decrease.



Package

Carton packing with liner of double polyethylene bags, Net weight 20kg each.





Storage and shippment

The product must be stored in ventilated, dry and clean room with temperature below 25°c Keep it away from fire, heat,and direct sunlight. Outdoor stacking is prohibited. Avoid rains and exposure to sunshine during shipment. The period of validity is 6 month under above condition. Expired products can not be used unless re-testing result meets the utilization standards.



Health and safety

There are no hazardous ingredients contained. Wearing anti-dust mask and goggles to avoid inhalation of dust. Try best to avoid longtime contact with powder. The coating adhesive to the skin can be washed with soap.



TGIC Free Polyester Powder Coating - Less Waste And Pollution To The Environment, Reduced Risk To Health.
