self adhesive luminous vinyl film

Name:Glow in the dark film/Photoluminescent self-adhesive PVC film/Luminous film/glow vinyl/glow PVC Vinyl

The photoluminescent film/luminescent film is made of rare earth photoluminescent pigment,after absorb any kinds of visible lights,such as sunlight,Lamp Light,UV light,it can glow in dark place for a long time.It has self-adhesive,so you can fix it easily,mostly,you can print any kinds of design on the surface by screen-printing. The process of absorbing-emiting can be repeated forever.

Property:

1)Appearance range: Yellow-Green, Blue-Green,Sky-Blue, Orange-Red, Blue, Green,Yellow,etc;

Films with self-adhesive vinyls,Rigid Board,Photo Paper,etc.

2)Glowing color range: Yellow-Green, Blue-Green,Sky-Blue, Orange-Red, Blue, Green,Yellow,etc;

3)Material:PVC and photoluminescent pigment with  self-adhesive vinyls in the back;

4)Suitable for any environment, such as high or low temperature, moist, acidity, basicity and need no outside energy;

5)Can be cut into many kinds of shapes or signs

Feature:

1)Short Storing-light time:10-20 min;

2)Long afterglow time:10~12 hours;

3)High luminance:40-90mcdM2 after 60 min;

4)Wide excitation wavelength:200-450nm,e.g. visible light, Lamp light,UV light;

5)Photoluminescent Pigment Recycle time:More than 10 years;

6)Safty:non-toxic/non-radioactive/nonexplosive/incombustibly/pro-environment

Application:

Used in furniture decoration or put onto the surface of switch,telephone,handle,stationery,toy,sport article or indication in the public area, recreation ground.

Usage Procedure and note:

1. Preferably to be applied for construction on smooth surface with the temperature of 10~40 Degree.

2. Cut the film into different sizes and can be directly pasted to the places like switch for decoration use.

3. It could be sticked directly with any designs sewed; or show the luminous designs with screen printing on the    films; or finish the luminescence with the designs made of non luminous tapes sticked on the films.

4. Clean the surface before pasting. No grease mark or dust allowed on the surface.

5. The film is expandable. Be careful not to dispose it at will and recommended to keep it pressed.

6. It is prone to humidity. Preferably have it processed in environment with 40%-60% in humidity.

7. Remove the paper from back and press neatly on the surface.

Specification:

Item No. Appearence Color      Glow Color Luminance After Luminance After  Specification(cm)
                                                                 10Min (mcd/m2 )  60 Mins(mcd/m2)  Suitable for all color

CH-MG-3A Light-Yellow         Yellow-Green             250               35                    30×400
CH-MG-A  Light-Yellow         Yellow-Green             190                28                    60×400
CH-MG-B  Light-Yellow         Yellow-Green             110                 15                    90×400
CH-MG-C  Light-Yellow         Yellow-Green             90                   9                     100×1000cm
CH-MG-D  Light-Yellow         Yellow-Green             70                   6                     Thickness:
CH-MB-A  Light-Green         Blue-Green                170                 24                   0.30mm-0.36mm
CH-MB-B  Light-Green         Blue-Green                100                  15
CH-MY-B  Yellow                   Yellow                       100                  15
CH-MR-B  Red                      Orange-Red               52                   12
CH-MS-B  Blue                      Blue                          40                    6
CH-ML-B  Green                   Green                        80                   15
