Antistatic Recording LD, Digidot HND, HNS Recording film

Product Overview

Description

Antistatic Recording LD, Digidot HND, HNS Recording Film





Red laser recording film RL-100E has the following characteristic:



>High sensitivity

>Sharp dot

>Good dot reproduction

>High density

>High film hardness

>Wide developing latitude

>Fast fixing and drying

>It's the same level with agfa, kodak, fuji brand film

It is suitable for image output for laser imagesetters with light sources from 632.8nm-670nm.



Red Laser Recording Film Applicable models:



Brand name	Model of machine	Light source
SCREEN	FT-R3020/5055	633nm/650nm
Fuji's Luxel	9000/6000	650nm
ECRM	VRL series&Mako	670nm
Creo	Dolev450/800v/800v2	632.8nm
Heidelberg	Signasetter Pro	632.8nm
	Herkules Pro	670nm
	ULTRE5800	670nm
AGFA	SelectSet Avantra series	650nm
Panther	Panther Pro46	670nm
Cron	ACF series	650nm
Eastcom	DX series	650nm



Film Sizes:

14"×60MT, 16"×60MT,18"×60MT,20"×60MT, 22"×60MT,

24"×60MT, 25"×60MT, 26"×60MT, 28"×60MT, 30" ×60MT ,

32" ×60MT , 33" ×60MT , 36" × 60MT, 44.5" × 60MT, 47.3" ×60MT.

Other sizes are also available as required.



Exposure:



Exposure should be determined by test according to the different type and the age of laser tube.



Processing:



Huaguang HG-2000 is recommended, others of same kind are also applicable.



Developing Temperature	30~32°C	34~35°C*
Developing Time	60~50s	45~35s
* Recommended developing condition for customers' first option
