Product Overview
Description
Advantage:
Vertical shaft gasoline engine
4--6hp gasoline engine
easy to start and carry
only 13KG
Photoes:
From now on,The plastic recoil starter have been changed into steel.that will be more durable.
Parameter and kinds of vertical shaft engine:
| Model No. | 1P68FV-C | 1P70FV-C |
| Engine type | Single cylinder,Flat horizontal,air cooled,4 stroke | |
| BorexStroke (mm) | 65x42 | 70x45 |
| Displacement(ml) | 163 | 173 |
| Compression Ratio | 8.0:1 | 8.5:1 |
| Theoretical Maximum Output Power | 4.0kw/3600rpm | 4.3kw/3600rpm |
| Rated output power | 2.5kw/3600rpm | 3.0kw/3600rpm |
| Horse Power | 5.5Hp | 6Hp |
| Max Torque | 6.8N.m/3000rpm | 9.0N.m/3000rpm |
| Ignition system | Non-contact Transistorized Magneto(TCL) | Non-contact Transistorized Magneto(TCL) |
| Start System | Recoil Start | Recoil Start |
| Air Cleaner | Semi-dry type | Semi-dry type |
| Fuel Tank Capacity | 1.8L | 1.7L |
| Fuel Consumption | ≤420g/kw.h | ≤395g/kw.h |
| Oil Capacity | 0.6L | 0.6L |
| Dimension (LXWXH)mm | 485x405x460 | 485x405x460 |
| Net Weight | 12KG | 13KG |
Usage:
Can be used for lawn mower,tiller,cultivator.
