Electric cargo vehicle AW2024H 2 seats with short cargo box
- Category: >>>
- Supplier: Suzhou Alwayz Electric Vehicle Manufacturing Co. Ltd.
Share on (60002997670):
Product Overview
Description
| 2-seater Electric Cargo vehicle | |
| Vehicle model | AW2024H |
| Main Specifications | |
| System Voltage | 48V |
| DC or AC | AC |
| Battery | 6pcs quality lead-acid batteries |
| Motor | 5KW AC |
| Controller | Curtis or Navitas |
| Passenger capacity | 2 |
| Max. range (loaded) subject to running on flat road at a speed of 20km/h (km) | >80 |
| Max. speed @10.25:1 gear ratio | 30 |
| Minimum turning radius (m) | 3.5 |
| Max. climbing ability (loaded) | 20% |
| Max. movement after brake at speed of 20km/h | ≤4m |
| Max. loading weight | 270kgs |
| Net weight | 410kgs |
| Cargo box | 770x1100x250mm |
| Overall dimensions | 2350X1180X1800mm |
| Other specifications | |
| Frame | Welded steel framework to be treated in dipping (phosphate)+electro-coating treatment |
| Body | PP plastic front body + PP plastic rear body |
| Roof | fiberglass or plastic |
| Windshield | Windshield, hinged |
| Large Seats: | |
| 1) backrest and cushion | Rebond seat + artificial leather |
| 2) armrest | plastic |
| Floor | rubber |
| Dashboard in black plastic | forward/reverse switch, battery capacity indicator, ignition key |
| Beverage holders | 4 cups drink holders |
| Side trim | Aluminum |
| Score card holder | on steering wheel |
| Towing bracket | on front of golf car |
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 LED taillights( each combined 1 brake light with 1 turn signal), with 20A voltage reducer (converting from 48V to 12V), horn. |
| Reversing alarm | \\ |
| Charger | on-board charger, input 110V-240V~50Hz-60Hz, output 36V/48V, 25A |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | Mechanical brake |
| Accelerator | Stepless speed change |
| Suspension system | Front and rear plate spring + cylinder hydraulic shock absorber |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Integrated, Gear ratio12.49:1 |
| Integrated, Gear ratio10.25:1 | |
| Wheel & Tyre | 10x6 Alumimum wheel & 205/50-10 4PR |
Company profile
Alwayszev is a leading company focus on R&D and Manufacturing of Low-speed electric vehicles which include Golf Car,Sightseeing Bus,Passengers Bus,Fire engine Car;Utility Car and various customized electric Vehicles,etc.
We have 2 factories, one is in Suzhou. The below is our Chuzhou factory which covers 15,000 square meters.It has
annual production capacity of 50,000 units vehicles.
Certifications
Advantages
1) Controller:
We use Navitas controller which is in 600A big power (big than anyone) and available with APP on mobile phone for easy operation.
2) Motor:
We use 5KW AC motor which is designed to work with above controller in order to offer both high speed and big torque.
3) Rear axle:
We use the best rear axle in the market which has been accepted by many American golf cart companies.
4) Battery:
We use the best battery in China which makes the battery for the military.
