100% Bayer virgin uv blocking soundproof polygal polycarbonate sheet

Product Overview

Description

100% Bayer virgin uv blocking soundproof polygal polycarbonate sheet:

Brief Introduction of polygal polycarbonate sheet :

Thickness:	4mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm
Width:	1220mm-2100mm.
Length:	5800mm,6000mm,11800mm.
Material:	100% virgin Bayer/Lexan material.
Color:	Clear, Green, Blue ,Brown ,Opal ,Red ,Yellow.
Coating:	50 micron UV protection(One side or two sides).
Guarantee:	10 years.
Certificate:	ISO9001:2008, ROHS , SGS.
Delivery Time:	7-10 days once confirm your deposit.
Payment:	T/T , LC , CASH .
Remarks:	Special size and colors can be customized.



Specification of polygal polycarbonate sheet :

Thickness (mm)	Structure	Weight (g/sqm)	Min. Bend Radius  (mm)	K Value (W/M2K)
4	2-layer	850	700	4.1
5		1000	875	3.8
6		1300	1050	3.6
8		1500	1400	3.3
10		1700	1750	3.0
6	3-layer	1400	1050	3.4
8		1600	1400	3.2
10		2000	1750	2.7
12		2100	2100	2.6
14		2400	2450	2.4
16		2600	2800	2.2



Features of polygal polycarbonate sheet :

1) Impact strength:	850J/m. About 200-350 times of common glass.
2) Light weight:	About 1/2 times of glass of the same thickness.
3) Light transmission:	80%-92% for different thickness of clear color.
4) Specific gravity:	1.2 g/cm3
5) Coefficient of thermal expansion:	0.065 mm/m° C
6) Temperature range:	-40° Cto 120° C
7) Heat conductivity:	2.3-3.9 W/m2 º
8) Tensile strength:	>=60N/mm2
9) Flexural strength:	100N/mm2
10) Heat deflection temperature:	140 ° C
11) Modulus of elasticity:	2, 400mPa
12) Tensile street at break:	>=65mPa
13) Elongation at break:	>100%
14) Specific heat:	1.16J/kgk
15) Soundproof index:	4mm-27dB,10mm-33dB



More pictures of polygal polycarbonate sheet :





Applications for polygal polycarbonate sheet :

1), Roofing skylight for office building,department store, hotel, stadium, school.

2), Soundproof shields on express ways.

3), LED diffused, Advertising lamp boxes, sign board.Telepohne booths

4), Anti-riot shield, bullet resistant material, Bank ATMs.

5), Agricultural greenhouses, zoos, botanical gardens.

6), Swimming Pools roofing/cover/sheet

7), Lighting for corridors, balcony, passages and subway entries, walkways.

8), Walls, roofs,windows,screens,shower enclosure.

9), Instrument and machine windscreen
