Single Color Flexo Printing Machine PP Woven Bag Printing Machine Flexographic Printing Press For Paper

Product Overview

Description

Single Color  Flexo Printing Machine PP Woven Bag Printing Machine Flexographic Printing Press For Paper





I.USE:

1).The cup flexo printing machine is used for BOPP,PET,PVC,PE Rolling Paper etc with good printing

performance of rolling material for multi-color continuous printing.

2).The cup flexo printer is also suitable for printing such packing materials as polyethylene, polypro-plane plastic bag,

glass paper and roll paper, etc.And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag,

vest bag and clothes Bag, etc.



II.charateristics:

1. Easy operation, flexible starting, accurate color register,good stability,reasonable price.
2.The meter counter can set printing quantity according to the requirements. Stop the machine automatically

at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the

machine stops.
6. 360°continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy

operate the machine when the plate is installed.
9. Magnetic powder brake for unwinding tension control,magnetic powder clutch for rewinding tension control.



III.machine show:



1)Main Parameter
Model:	XHYT-1600mm
Max Width of Material	600mm
Max.Width of Printing:	560mm
Material:	Paper,Non-woven fabric,Woven Fabric ,Film(PE,PVC,OPP,BOPP,NY:15~120μm,PET:15~100μm,CPP)and so on
Printing color:	1color
Max.Length of Printing	200-1100mm
Machinery mechanical speed	10-90m/min
Max.Speed of Material Printing	10-80m/min(according to the printing materials)
Thickness of Plate (including the glue)	2.28mm
machine weight	1800Kg
machine dimension (L×W×H)	2.5m×1.6m×1.6m
