digital timer water pump controller

Product Overview

Description

MULTI-FUNCTION PRESSURE CONTROLLER





TECHNICAL DATA:

• Staring Pressure:1-6Bar(Adjustable)


• Stopping Pressure:2-10Bar(Adjustable)


• Min Differential Pressure:1 Bar


• Max Differential Pressure:7 Bar


• Max Rated Current:10A


• Max Allowable Pressure:10bar


• Rated Voltage:110V-120V or 220V-240V


• Frequency:50/60HZ


• Max Ambient Temperature:40°C


• Max Liquid Temperature: 60℃


• Protection Degree:IP65

DESCRIPTIONS:

• Multi-function photoelectric pressure controller used in water systems.


• Stopping the pump automatically when water shortage.


• Can manual set whether need to pressure stop function.


• Restarting the pump automatically after idling stop, standard detect interval is 1 time/hour


• Built-in with two operational modes(Model 1 and Model 2),can manually switched according to needs. Choose “Model 1”,can set stopping pressure(betweeb2-10 bar adjustable.)When the pressure in the pipe is higher than or equal to the setting stop pressure, pump stopping, or in the standard maximum pressure of the pump when the flow stop(tap closed)corresponding to close the pump, when the pressure become weak(tap open)corresponding to turn on the pump .
  Choose ”Model 2”,in the standard maximum pressure of the pump, when the flow stop(tap closed),pump closing; when the pressure become weak(tap open),pump starting.


• Thread connection:G1”Male.


• Completely replace traditional pump control system composed of pressure switch tank and check valve, etc.


• Customeized setting

Optionals:

• Color.


• G1"plastic pipe joint for a quick connection to water pump.


• Power cable length can choose according to customers' needs.

Packing size:



PACKING SIZE(cm)        50.5*34.5*21
PCS/CTN                 12
N.W.(KGS)               9.20
G.W.(KGS)               11.00



Main market:

• EUROPE


• MIDDLE EAST


• SOUTH AMERICA


• ASIA


•
