TNS fashionable design rotary cultivator parts, 008618867595607

Product Overview

Description

GN-12/GN-15

MODEL				GN-12
Overall dimensions:(L×W×H)				2950×980×1240mm
Wheel tread				570,630,690,750,810mm
Tyres				6.00-12
Ground clearance				210mm
Working weight (with rotary tiller)				500kg
Speed		Forward		1.39, 2.47, 4.15, 5.14, 9.12, 15.30
(km/h)		Reverse		1.10, 4.10
		Turning speed		Low:199,	High:250
Rotary tiller		Width		600mm
		Number of blades		18pcs
		Model		S195N
		Type		Single cylinder,4-stroke,horixontal,water-cooled,diesel
		Cooling mode		Condenser (Radiator)
		Rated power		9.7kw
Engine		Rated speed		2000rpm
		Fuel efficiency:		≤244.8gl/kw.hr
		Net weight		150kg
Main farm implements				1)Anti-skid steel wheel;
				2)Double-plough (optional)
				3)Trailer(optional)
Packing		Case dimensions		116×108×108mm
		N.W/G.W.:		500/600KG
Conveyance:		Qty/20' FCL.:		20pcs
		Qty/40'(HQ) FCL.:		40pcs(packing mud wheel inside box), 36pcs(packing mud wheel outside box)
