Manufacturer high quality AC90 150V pir sensor motion switch e27 human body induction lamp holder 86mm LED energy conservation

Product Overview

Description

The company for customers to design various types products of electronic, provide solutions, the price is cheap, first-class service.



Hello! We also have alibaba China  store, please click link for  details: //jianglongdianzi2011.1688.com

We also take OEM, ODM orders upon request, if you any questions, please feel free to contact us.

The human body induction lamp holder operation instruction

          (JL-009B Adjustable     sensitivity and time)

1. Suitable for places

Corridor,toilet,basement,garage ,and other places of automatic lighting.

2. Features:

Our products adopt the most advanced imported internal sensor and circuit, when pedestrians into the sensing range light will start automatically, when they leave light will delay and shut down automatically. It has:

1,Wide working voltage, normally working in90V-150V,50/60HZ

2,Large power, impedance biggest load can reach60W

3,Delay time adjustable(JL-009B specific)

4,Sensitivity adjustable(JL-009B specific)

5,Strong anti-jamming capacity, more safe and reliable

3.Specification:

1,Working power:AC90V~150V,50/60HZ

2,Load power:≤60W

3,Power consumption Idling:≤0.1W

4,load characteristic:energy saving lamp,LED

5,Delay time:15~300second(default 30S)

6,illumination:5LUX~5000LUX(default 5LUX)

7,Induction distance:110°,5~8m

4. Attention:

1,To turn off power when installation, must be installed by professional

2,Do not overload to use

3,This product should not be used for the incandescent light bulb

4,This switch can work normally after 60 seconds when electricity, it is infrared sensor preheat time



Components have been doing rigorous testing and screening, before delivery we have been doing aging test, please be assured to use
