BAOMA branded high configuragion used wire edm DK7740F
- Category: >>>
- Supplier: Suzhou Baoma Numerical Control Equipment Co. Ltd.
Share on (60013232720):
Product Overview
Description
BAOMA branded high configuragion used wire edm DK7740F
MACHINE MODEL
| ITEM | B | D | F | H |
|---|---|---|---|---|
| Max. Cutting Thickness(mm) | 500 | 500 | 500 | 300 |
| Max. Cuttting Taper(<=100mm thick) | 0 | ±3° | ±30° | ±3° |
SPECIFICATIONS
| CNC Wire Cut EDM DK7740 | DK7740B | DK7740D | DK7740F | DK7740H | |
|---|---|---|---|---|---|
| Table Travel (mm) | 400 x 500 | ||||
| Table Size (mm) | 500 x 785 | ||||
| Roughness | Once Cutting (um) | <= 2.5 | |||
| Multi-Cutting (um) | <=1.5 | ||||
| Precision | Octagon (mm) | <= 0.015 | <= 0.015 | <= 0.015 | <= 0.015 |
| Taper (mm) | <= 0.04 | <=0.1 | <= 0.04 | ||
| Screw and guide way | High Quality Ball Screw ; Steel Linear guideway | ||||
| Load of Table (Kg) | 500 | ||||
| Machine Weight (Kg) | 2000 | ||||
UNIVERSAL PARAMETERS
| Max. Cutting Speed | 150 mm2/Min. |
| Wire Speed | 5 - 11 m/Min |
| Max. working Current | 6 A |
| Wire Diameter | Dia. 0.15-0.2mm |
| Work Solution | BM50/BM4 Water Base Working solution |
| Water Tank | 100 L |
| Rated Voltage | AC~,3N, 220-415V,50/60HZ |
| Ratde Power | 3 KVA |
| Wire Guide Frame | Adjustable |
| Controller | BMW-3000 |
FEATURES:
Control System | |
|
|
Pump and Tool Box | |
|
|
PACKING: | |
|
|
c)CERTIFICATE
SGS TEST
OUR WORLD EXPOSITION
EGYPT:
BRAZIL:
BEI JING:
INDIA:
