6.1m 20 feet Large Diameter Industrial Ceiling Fan
- Category: >>>
- Supplier: Shanghai Aipu Fans Co. Ltd.
Share on (60020552265):
Product Overview
Description
Product Description
HVLS CEILING FAN
Large ceiling-mounted industrial ventilation fan* High air-volume HVLS fan
* Imported Germany motor, IE2, IP55
* Digital VFD controller, IE2, IP55
* 6x Aluminum-magnesium alloy blades
* Highly efficient & energy-saving
Large ceiling fan by the fan continue to push forward, and produce a large number of air blowing to the around, the air flow to both sides of the flow, the information of large area of the airflow, through the control of the fan, get the average wind speed of 1-3 m/s comfortable cool wind. Breeze blowing in the human body, will promote the sweat away to take away the heat, leaving the body gradually cool, bring comfort. Usually, this cooling can feel about 3-5 degree. They are mainly used in large and high places
like workshop,warehouses,distribution center, gymnasium, station, farm and so on.There are many top 500 companies in the world such as Wal-Mart, HONDA, NISSAN, FORD etc are our loyal customers.
Detailed Images
COMPACT DIMENSIONS
- AWF SERIES
SIZE: 7 FT -28 FT (2100 MM - 8600 MM)
BLADE QTY: 4/5/6/8/10 PCS
POWER: 0.75KW/1.1KW/1.5KW/2.2KW
VOLTAGE: 220V/380V/440V
HIGH EFFICIENT & ENERGY-SAVING
COVERAGE UP TO 2000 SQM
HIGH GEARED MOTOR
DIGITAL VFD CONTROLLER
BLADE QTY: 4/5/6/8/10 PCS
POWER: 0.75KW/1.1KW/1.5KW/2.2KW
VOLTAGE: 220V/380V/440V
HIGH EFFICIENT & ENERGY-SAVING
COVERAGE UP TO 2000 SQM
HIGH GEARED MOTOR
DIGITAL VFD CONTROLLER
MAGNESIUM ALUMINUM ALLOY BLADES
CUSTOMIZED COLORS
EXTENSION TUBE: 0.5M TO 3M
All the fasteners are Diameter of 14 mm high strength bolts and non-slipping self-locking nuts;All ceiling fans are equipped withfrequency conversion control system device;
All ceiling fans are equipped with H-beam buckle mounting parts;
All ceiling fans are equipped with preventing air turbulence tail and propeller blades.
All ceiling fans are equipped with H-beam buckle mounting parts;
All ceiling fans are equipped with preventing air turbulence tail and propeller blades.
Safety alarm device, built-in overload phase protection, timely alarm signal to ensure safe running. The perspective window is designed to observe the operating parameters of the fan conveniently
Blade safety connection pieces connect the blades one by one to the blade brackets (Even if the blades brackets are broken, the fan would not falling off due to the connecting piece device.)
Each fan is equipped with 4 pcs of steel wire rope (enhance the stability of ceiling fan, to prevent the risk of loosening of
screws)
screws)
Motor System - imported Germany Nord motor
1. Low backlash assembly process and gear grinding technique, low noise2. Strength the bearing frame structure, increase oil seal
and strength the motor structure with trapezoidal shaft structure, higher safe;
3. IP55 protection grade, IE2 stardard
4. Passed CCC, CE, UL certificates
5. Can run on clockwise and counterclockwise direction
and strength the motor structure with trapezoidal shaft structure, higher safe;
3. IP55 protection grade, IE2 stardard
4. Passed CCC, CE, UL certificates
5. Can run on clockwise and counterclockwise direction
Control System - VFD Controller
1. Danfoss electrical sets, with safety protection module inside which will interrupt the output automatically in case of some
accidents.
2. Protection level is IP55, passing UL, EMC, ROHS certificates;
3. Safety & Protection: over-load, over-current, cutting off t he power automatically in emergency situation
accidents.
2. Protection level is IP55, passing UL, EMC, ROHS certificates;
3. Safety & Protection: over-load, over-current, cutting off t he power automatically in emergency situation
Patented Airfoil Blades
High strength aircraft grade magnalium, fluorocarbon painting on surface, aerodynamic fan blade design. Patented fan blade design:
3 sets reinforcing rib supports system inside, enhance the strength of fan blades and avoid sagging of fan tail and fatigue loss
of connecting components.
3 sets reinforcing rib supports system inside, enhance the strength of fan blades and avoid sagging of fan tail and fatigue loss
of connecting components.
Product Presentation
Product Name | HVLS ceiling fan |
Material | magnesium aluminum alloy |
Power | 1.5kw |
Voltage | 220V/380V/440V |
Air volume | 9800m3/min |
Model | AWF61 |
Blade | 4/6/8/10PCS |
Height | 1200mm |
Size introduction and size picture
One set of the fan will be packed into 2 cases
Item | Length | Width | Height | Volume | |||
1 | 800mm | 800mm | 500mm | 0.32cbm | |||
2 | 2950mm | 260mm | 280mm | 0.21cbm | |||
Total Volume | 0.53cbm | ||||||
Certificate
Related Products
Company Introduction
Shanghai Aipu Fans Co., Ltd was established in Shanghai, China. Since its establishment in 2006, it has been manufacturing industrial-grade high-quality ventilation products, aiming to provide the fastest pre-sale, after-sale and the best ventilation solutions. Based on the industry-leading concept and manufacturing technology, AIPU technology with abundant technical advantages, first-class product quality and advanced management concepts, has grown into a R&D, production and marketing as one of the integrated company with core technology. Aipukeji has always been committed to the pursuit of excellence in quality, to meet customer demand, to create high-quality products.
We have 8000 square meters of production base, equipped with high-precision automatic production machine. The products produced by the automatic machine have higher quality and higher cost-effective, and the automatic machine is also the guarantee of our high productivity. The factory is equipped with the latest production equipment and production technology, the establishment of a machining center, cutting center, welding center and testing center. Aipukeji’s products are sold well all over the world and are highly praised by domestic and foreign clients.OEM is available!
Packing&Shipping
FAQ
Q1. Are you the factory?
A: Of course, we are large ceiling fan manufacturer in Shanghai with many years' experience.
Q2. What about the lead time?
A: It can be within 3-5 days after receive the payment if the order is less than 20 sets.
Q3. Do you have any MOQ limit for HVLS CEILING FAN?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order for HVLS CEILING FAN?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the specification parameter and places deposit for formal order.
Fourthly We arrange the production.
Q5. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
A: Of course, we are large ceiling fan manufacturer in Shanghai with many years' experience.
Q2. What about the lead time?
A: It can be within 3-5 days after receive the payment if the order is less than 20 sets.
Q3. Do you have any MOQ limit for HVLS CEILING FAN?
A: Low MOQ, 1pc for sample checking is available
Q4. How to proceed an order for HVLS CEILING FAN?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the specification parameter and places deposit for formal order.
Fourthly We arrange the production.
Q5. Is it OK to print my logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
