1200C dental laboratory wax furnace , dental laboratory steam cleaner

Product Overview

Description



We specialize in the production of various laboratory furnace, box furnace, vacuum furnace,

rotary tube furnace, high temperature atmosphere furnace, pallet car furnace and bottom lifting

furnace, over the years we adhere to customer demand-oriented, committed to continuously

improve product quality and perfect markets.



Model: KJ-1200X muffle furnace dewaxing furnace burnout furnace / dental laboratory steam cleaner

Size: 100*100*120mm (WxHxD)



Features:



1. Operation Temperature: 1100°C ( 1200°C for short time).

2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient

    alumina fiber ceramic insulation.

3. Three sides resistance wire coil for fast and uniform heating.

4. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.

5. 0.5" diameter observation window made of quartz glsss, allows users to see inside chamber

    during heating operation.

6. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon

    Controlled Rectifier).

7. Power control with 50 segments programmable.

8. Vent port (gas outlet) installed on the top for gas flow.



Descriptions:



Chamber Size	100x100x100mm (WxHxD) (or can be designed as your requirement)
Working Temperature	1100°C
Maximum Temperature	1200°C
Heating Rate	0~15°C/min (suggestion: ≤10°C)
Temperature Accuracy	+/-1°C
Temperature Controller	50 steps programmable and auto control
Heating Element	Ni-Cr wire
Voltage	AC 220V, Single Phase, 60/50 Hz  (or according to your requirement)
Max. Power	750 W
Outside Size	350x350x550mm
Net Weight	20 Kg







Package: Plastic paper inside, Polyfoam filled, Wooden box outside.

Payment: T/T, West union, etc.

Shipping and Delivery: by air/sea, in 15 days after receiving the payment

Warranty: 1 year limited warranty on all electronic parts.



1. Reply your inquiry in 24 working hours.

2. Experienced staffs answer all your questions in fluent English.

3. Customized design is available.

4. Exclusive and unique solution can be provided to our customer by our well-trained and

    professional engineers and staff.

5. Professional factory : We are manufacturer, specializing in laboratory furnaces.
