Hot seller KX 5188A35 induction hardening melting induction furnace high frequency induction heating machine
- Category: >>>
- Supplier: Yueqing Kexin Electronic Instrument Co. Ltd.
Share on (60027709293):
Product Overview
Description
Product Overview
KX-5188A35 High Frequency Induction Heating Machine
Based on the principle of electromagnetic induction,our machine could make induced current generate inside the metal material, which is in the alternating magnetic field.Then this current could heat the material up to the melting state.
FEATURES AT A GLANCE
1) Germany SIEMENS INFINEON IGBT Module(40-60KHZoscillation frequency,fast response time, high arcstability, almost spatter-free welding)
2) Japen Nichicon electrolytic capacitor(filter capacitor)
3)signal circuit, drive circuit board ,control circuit board and components are adopted:Toshiba, Hitachi,Motorola,China's top
manufacturers
4)international advanced all-solid-state semiconductor power devices
5)imported transistor integrated block
6)high speed control tube
7)with perfect control,protection,alarm display circuit,machine could get full automatic tracking frequency, continuous adjustable
power,safe and dependable protection,clear and accur data display and etc technical advantage
2) Japen Nichicon electrolytic capacitor(filter capacitor)
3)signal circuit, drive circuit board ,control circuit board and components are adopted:Toshiba, Hitachi,Motorola,China's top
manufacturers
4)international advanced all-solid-state semiconductor power devices
5)imported transistor integrated block
6)high speed control tube
7)with perfect control,protection,alarm display circuit,machine could get full automatic tracking frequency, continuous adjustable
power,safe and dependable protection,clear and accur data display and etc technical advantage
PRODUCT SPECIFICATIONS
No | Model | KX-5188A35 |
1 | Rated Power output | 35KW |
2 | Frequency range | 30-80 KHz |
3 | Input Current | Three-phase 380V /50HZ |
4 | Current input | 5-45A |
5 | Efficiency | 95% |
6 | Duty cycle | 100% |
7 | Volume(mm 3) | 760 mmx310mmx540mm |
8 | Net Weight | 46KG |
9 | Gross Weight | 60KG |
10 | Cooling water flow | hydraulic pressure≥0.2MPa,flow rate:5-20L/Min |
11 | Cooling water temperature | ≤ 40°C |
12 | Waterway of power supply | Control box: 1 inlets, 1 outlets |
13 | Application | Quenching, annealing, conditioning saw blades, drill, welding standard parts of axial, fastener local heating, forging, melting; |
PRODUCT CONFIGURATION
PEDAL CONTROLLER
INDUCTION COIL
COPPER TUB
Successful Project
TUBE WELDING
GEAR HARDENING
METAL MELTING
SIMILAR PRODUCTS
FAQ
1. Which countries your products are exported to?
Our products have been sold all over the world and with related certifications.
2. How about the warranty?
All our products have one year quality warranty, during the warranty period, the spare parts for replacement are free. And we provide life long technical support and other assistance.
3. How to install your machine?
We have installation instruction papers and videos, we will teach till you can do it yourself.
4. What about delivery?
We offer assistance on seeking best shipping way and suitable forewarder .
Any loading port and any destination city address are both ok for us
5. How about the payment terms and delivery time?
Payment terms for any machines: 100% T/T/ Western Union/ESCROW with buyer protection
We have machine in stock,so we surly will send out the machine after geting payment in one day ,if no any special adjustment requirest from clints.
6. If I have paid but can not receive the goods, how should I do?
Alibaba international website is a famous trade website and it has run very well these years.
Every supplier on it has paid a large amount membership fee, and spare much effort to manage their business well, we have Chinese business licenses which can be checked on Chinese official website or we can show it to you,and these licenses are also kept back-up on Alibaba , if we do anything illegal without honest,we would get punished very badly after yousued us.so that your concern will never appear, please do not worry
7. Is your goods has CE certificate?
Yes, all our goods has CE certificated. All machines are high quality goods.
8. What is your company: Trader or Manfacturer ?
We are manufacturer and have a big factory , warmly welcome to visit our factory and contact us.
Our products have been sold all over the world and with related certifications.
2. How about the warranty?
All our products have one year quality warranty, during the warranty period, the spare parts for replacement are free. And we provide life long technical support and other assistance.
3. How to install your machine?
We have installation instruction papers and videos, we will teach till you can do it yourself.
4. What about delivery?
We offer assistance on seeking best shipping way and suitable forewarder .
Any loading port and any destination city address are both ok for us
5. How about the payment terms and delivery time?
Payment terms for any machines: 100% T/T/ Western Union/ESCROW with buyer protection
We have machine in stock,so we surly will send out the machine after geting payment in one day ,if no any special adjustment requirest from clints.
6. If I have paid but can not receive the goods, how should I do?
Alibaba international website is a famous trade website and it has run very well these years.
Every supplier on it has paid a large amount membership fee, and spare much effort to manage their business well, we have Chinese business licenses which can be checked on Chinese official website or we can show it to you,and these licenses are also kept back-up on Alibaba , if we do anything illegal without honest,we would get punished very badly after yousued us.so that your concern will never appear, please do not worry
7. Is your goods has CE certificate?
Yes, all our goods has CE certificated. All machines are high quality goods.
8. What is your company: Trader or Manfacturer ?
We are manufacturer and have a big factory , warmly welcome to visit our factory and contact us.
