Product Overview
Description
100Cr6 Round Bar Sae 52100 Steel Price 52100 Steel
1. Chemical composition
| C | 0.93-1.05% | Cr | 1.35-1.60% |
| Si | 0.15-0.35% | Mo | ≤0.10% |
| Mn | 0.25-0.45% | Al | ≤0.050% |
| P | ≤0.03% | W | - |
| S | ≤0.015 | O | ≤0.0015% |
2. Equivalent Steel Grade
| DIN | 1.3505 |
| ASTM A295 | 52100 |
| JIS G4805 | SUJ2 |
| BS 970 | 535A99 EN31 2S135 |
| GB | GCr15 |
| EN / ISO 4957 | 100Cr6 (B1) |
| SWEDEN | SKF3 |
3. Hardness
Annealed ≤207HB, Cold drawn ≤331HB.
Q+T Properties
| Tensile Strength | σb (MPa):≥500 |
| Yield Strength | σs (MPa):≥415 |
| Elongation | |
| Reduction | |
| Impact Energy | |
| Impact Toughness | |
| Annealed Hardness | ≤207HB |
4. Surface Treatment
Plate: Origin Black, Orign cold rolled bright, Machined, Grinded
Bar: Origin Black, Orign cold rolled(drawn) bright, Turned, Peeled, Grinded
5. Size
Round bar: Diameter(mm) Max 800mm; Length(mm) Max 12000mm.
Plate: Thickness(mm) Max 800mm; Width(mm) Max 2300mm; Length(mm) Max 12000mm.
Condition: Cold rolled(drawn)≤50mm, Hot rolled≤12-250mm, Hot forged≥50mm.(Thickness/Diameter)
6. Heat Treatment
1)Soft Annealing
Heat to 760-800o C, cool slowly in furnace. This will produce a maximum Brinell hardness of 207.
2)Stress Relieving
Stress relieving to remove machining stresses should be carried out by heating to 650o C, holding for one hour at heat, followed by air cooling. This operation is performed to reduce distortion during heat treatment.
3)Hardening
Harden from a temperature of 830-870o C followed by oil quenching. Hardness after quenching is 64 HRC.
4)Tempering
Tempering temperature: 150-180o C.
5)Forging
Hot forming temperature: 1200-926℃.
6)Welding
This is a high carbon alloy typically used in bearing applications where welding is not applicable or appropriate
