PT100 heraus class b M222 Thin film PT100 sensor element

Product Overview

Description

I.  Name:  PT100 heraus class b M222 Thin film  PT100 sensor element

II. PT100 sensor element   Quick Details





Place of Origin:	Fujian China (Mainland)	Brand Name:	XBL	Model Number:	M222
Usage:	Industrial	Theory:	Temperature Sensor	material:	platinum rhodium,ceramic
Graduation mark:	pt100/pt1000	temperature:	-50-450c	Class:	A/B





III. PT100 sensor element  overview



Thin film platinm resistance temperature detecyors (Pt-RTD) consist of a thin film platinum



deposited on a ceramic substrate.Thin film Pt-RTD's provide cost advantages when compared



to wire wound Pt-RTD's because of their lower material cost factor.





IV. PT100 sensor element  Specifications





1.material:platinum rhodium,ceramic



2.Ceramics size:3.2*1.6*1.0



3.Chip size:2*2.3*1.3



4.temperature:-50~450C



5.ISO9001-2008



V. PT100 sensor element  GENERAL CHARATERISTICS:



1.BROAD APPLICATION TEMPERATURE RANGE: -50^oC TO +650^oC



2.NOMINAL RESISTANCE VALUE AT 0^oC: 100 OHM



3.AVAILABLE TCR: 0.00385



4.STANDARD ACCURACY: IEC751 AND DIN43760



5.LINEAR RELATIONSHIP BETWEEN RESISTANCE AND TEMPERATURE



6.MICROPROCESSOR-BASED SENSOR CAPABILITY



7.FAST RESPONSE, RELIABILITY, ACCURACY, STABILITY, INTERCHANGEABILITY



8.EXCEPTIONAL ENDURANCE TO SHOCK AND VIBRATION.



Germany import  pt100 thin film platinum resistance





model number Ceramics size Resistance value(Ω) current accuracy measure range Components appearance(mm) WZP 3.2×1.6×1.0 Pt100 ≤1mA A  B 2B A -50~400°C  B -50~500°C   WZP 5.0×2.0×1.0 Pt100 ≤2mA

grade accracy (°C)  tolerance A ±(0.15+0.002t) ±0.06 B ±(0.30+0.005t) ±0.12 2B ±(0.60+0.001t) ±0.25
