Multilayer flexible cross laminated polyethylene roll film
- Category: >>>
- Supplier: Upass Material Technology (Shanghai) Co. Ltd. [Shanghai China]Upass
Share on (60037939948):
Product Overview
Description
Multilayer flexible cross laminated polyethylene roll film
Invention Patent (Patent No. ZL 2014 1 0048324.2)
Third prize of The 19th China International Industrial Exposition
First prize of technical Progress Award for Building Waterproofing Industry
Vice Chairman Unit of China Waterproof magazine
Vice Chairman Unit of Shanghai Society for Advanced Materials
Vice Chairman Unit of China Innovative benchmarking enterprise
Executive Member of the 7th Council of China Building Waterproofing Association
The strength film can be used to produce outside label,
We are only professional factory which focus on manufacturing HDPE release film and high strength cross laminated film for waterproof membrane,outdoor label,self adhesive tape,special package etc.we focus on high class products.
Product Description
HDPE Cross Laminated Strength Film
1,strong tensile strength,anti sun,no bubbles.
2,high strength roof composite material,creep resistance,Puncture resistance,anti aging
3,high strength, deformation resistant,weather resistance
Usage:Surface film for self adhesive Bitumen waterproof membrane /label/special package
Datasheet:
| Thickness,Width,Unit Weight | |||||
| Item No.: | SDM30 | SDM60 | |||
| Thickness | 0.14 | 0.1 | |||
| 1 | Thickness tolerance | Thickness limiting tolerance≤ | ±0.025 | ||
| Thickness average tolerance≤ | ±10% | ||||
| 2 | Width tolerance/mm | ≤ | ±3 | ||
| 3 | Unit weight(g/m2) | ≥ | 130 | 90 | |
| Physical and mechanical property | |||||
| Item | SDM30 | SDM60 | |||
| 1 | tensile properties | tensile strength/Mpa ≥ | 30 | 50 | |
| pulling force(N/50mm) ≥ | 200 | 250 | |||
| The maximum tensile elongation ≥ | 200 | ||||
| Elongation at break ≥ | 250 | ||||
| 2 | Number of not breaking test sample when dart drop dash | 8 | |||
| 3 | A nail rod tear strength /N | 25 | |||
| 4 | tear strength/N ≥ | 25 | |||
| 5 | heat resistance | 120℃ 10minutes,no bubbles, Not laminating | |||
| 6 | low temperature flexibility | -35℃ no cracking, Not laminating | |||
| 7 | heating ageing | appearance | no bubbles, Not laminating | ||
| Pull retaining rate ≥ | 80 | ||||
| The maximum tensile elongation ≥ | 200 | ||||
| Elongation at break ≥ | 200 | ||||
| 8 | artificial weathering accelerated aging | appearance | no bubbles, Not laminating | ||
| Pull retaining rate ≥ | 70 | ||||
| The maximum tensile elongation ≥ | 180 | ||||
| Elongation at break ≥ | 180 | ||||
| SDM Strength film for Waterproofing membrane,then test 1,3,4,5,6,7,8,for other application,then test 1,2 | |||||
