Product Overview
Description
wood pellet mill, pellet mill, wood pellet machine, pellet machine,wood pellet press, pellet press hot selling.
1.Adwangtages:
Pellet mill can make the fullest use of natural resources, have good rigidity, perfect
smoothness, long shelf life and standard degree of moistness. The fodder will be
nearly cooked during the processing which can greatly increase the proportion
of take-in nutrition. And reduce the zymolysis time of fertilizers.
2.Applied Range:
The pellet mill can be used for heat daily or mixed fodder by corn, beans, straw, grass meal, bamboo, sawdust etc.
3.Main Market:
North America
South America
Asia
Africa
Oceania
Western Europe
Easstern Europe
4.Specification:
Model | Wood capacity | Feed capacity | Power | N/G weight | Pellet diameter | Outside(cm) | ||
Length | Width | Heigth | ||||||
KL120B
| 20-30kg/h | 40-70kg/h | 2.2kw /3kw | 80/100kg | 2.5-10mm | 75 | 31 | 62 |
KL120C | 30-50kg/h | 50-100kg/h | 2.2kw /3kw | 80/100kg | 2.5-10mm | 75 | 31 | 62 |
KL150B | 50-100kg/h | 100-200kg/h | 4kw | 100/120kg | 2.5-10mm | 77 | 34 | 68 |
KL150C | 50-100kg/h | 100-200kg/h | 4kw | 100/200kg | 2.5-10mm | 77 | 34 | 68 |
We also have the NEW type KL120V-KL150V.
| Model | Power | Capaciy(kg/h) | Packaging size | Pellet diameter | N/G weight | Moisture | Qty/20'/40' |
| KL120V-1.5KW | 1.5kw 220v single | 20-40kg/h | 60*39*68cm | 2.5-10mm | 60/80kg | 8%-20% | 112/240set |
| KL120V-2.2KW | 2.2kw 220v single | 30-60kg/h | 60*42*105cm | 2.5-10mm | 65/85kg | 8%-20% | 100/210set |
| KL120V-3KW | 3kw 380v 3phase | 50-100kg/h | 60*42*105cm | 2.5-10mm | 70/90kg | 8%-20% | 100/210set |
| KL150V-4KW | 4kw 380v 3phase | 100-150kg/h | 70*52*110cm | 2.5-10mm | 80/100kg | 8%-20% | 65/140set |
5.Function:
The KL series pellet mill can be powered by both diesel engine and E-motor. We adopt the new design of direct connection of motor shaft and he main shaft that
overcome the loose defect of belt connecting as long time using.
When the fodder is added in, the template, pressing roller and fodder will be
heated to 60-80 digree by the friction among them. After being pressed through
the template, the fodder will be thrown from the machine in a state of granular. You can choose the size of the granules by using diffrent template with different size of holes in it.
A diesel eingine is another choice to drive the machine, together with the clutch and
accelerating-decelerating device to change its speed. It is still for the belt to drive
the main shaft. The machine can run smoothly and with few noises.
