G1WG1000 Paste filling machine Semi auto

Product Overview

Description



Horizontal single head paste filling machine oil filling machine

Product Description

Functions And Features

This serier filling machine is designed accord to the foreign advantage technical. Itwith simple structure, stuer, high accuracy and easy th heopperation, suit for medicine daily use foodstuff pesticide and any other special filed. It is the bests equipment  to fill high thicness material and paste. Accord to GMP, the parts which connect with material are all made of stainless steel. Machine with filling volume adjustable handle, filling speed also can be changed as you like, high accuracy. Filling nozzle designed with nozzle model, double nozzles modle and explosion proof modle.



SPECIFICATIONS FOR PASTE FILLING MACHINE

Modle	G1WGD100-5000
Voltage	AC220V 50HZ
Power	20W
Air pressure	0.4-0.6MPA
Filling speed	5-30Bottle/Min
Filling Accuracy	≤±1%
Filling range	10-100ml 30-300ml 50-500ml 100-1000ml 500-3000ml 1000-5000ml
Machine size	1060-1450mm*360-400mm*360-450mm



Sample





G1WG1000 Semi-auto Paste filling machine



Features

1.Be used for filling with particulate matter sauce,paste,liquid and other material;
2.Material connect parts used 304 stainless steel;
3.Pneumatic and electric control, easy to operate,remove and clean; Ideal equipment for filling inflammable, explosive materials.



Parameter Data

Fillable range:10-100ml,50-300ml,50-500ml,100-1000ml,1000-5000ml (customized)

Filling speed : 0-40 pcs/min (depending on operator speed, product density, draw length, a fill speed, among others)

Air pressure:0.4MPa

Material:Stainless steel

Automatic Grade:Semi-Automatic

Filling accuracy :±1%

Air pressure range  :  4-6kg/cm2

Power:pneumatic

Driven Type:Pneumatic and electric  ( total pneumatic can be made accord to customized)

Filling head: Single head or Double Head or Customized



Package

Safe package: carton+foam or wooden case

Shipping package size:1300*370*360

Tank shipping package size 430*430*510mm

Place of Origin:Wenzhou China (Mainland)

Machine G.W: 27KG

Tank G.W:5KG

Our Company

Wenzhou Haizhou packing machine Co,ltd. is located in Xianyan Town Ouhai district, Wenzhou city,we have advanced management concept, outstanding R&Dteam, innovative science and technology, thorough presale, in sale and after sale service system.we combined with domestic and international advanced packaging concept to create first-class packaging machinery all over the world.we are a long-established factory specializing in providing packaging equipment for toothpaste, cosmetics,food, beverage,daily chemical, agrochemicals,fine chemical,and other industries. Our main equipment is: tube filling and sealing machine,cup filling and sealing machine,fillling and capping machine, automatic cartoning machine and their related production lines.
