Airport Luggage Convey Belt Security Scanner Digital X ray Machine JUZHUO6550

Product Overview

Description

Airport Luggage Convey Belt Security Scanner Digital X-ray Machine  JUZHUO6550



FEATURE

1,Alarm by sounds & light::Alarm by sounds and light when conform to condition.

2,Network interface:Could be connect local area network and support multi-terminal check baggage at same times

3,Safety ray:Transmit ray under automatic control, avoids the miss.

4,Simple operation by mouse:Without keyboard and work table, control by mouse, save space.

5,Turn off by a key control:Turn off the machine only need one step:revolves the key. The equipment 6,automatic security close-down, does not need complex many steps, is simpler.

7,  Eagle-eye:Could be expediently observing enlargement area.

8,Estimate malfunction by self:Automatic estimate malfunction and prompt message, helpful for the maintenance.

TECHNICAL DATA

Tunnel Size:                    650(W)×500(H)mm

Conveyor Speed:                 0.22 m/s 1

Conveyor Max Load:            100 kg

Single inspection dosage           < 1.5µGy

Wire Resolution:                 0.1mm metal line

Steel Penetration:                 30MM armor plate

Film Safety:                     For ISO 1600

Maximum leakage radiation        <0.3µGY/H

X-RAY GENERATOR

Orientation:                        Vertically Upward

Tube Current:                       0.4~1.2MA(adjustable)

Anode Voltage:                      100~160 KV(adjustable)

Angle:                             80°

Generator cooling/working periods       Sealed oil bath with forced air/100%

IMAGE PERFORMANCE SYSTEM

1,X-RAY SENSOR:  L TYPE PHOTO-DIODE ARRAY DETECTOR, 12BIT

2,MONITOR:  HIGH RESOLUTION 17INCH COLOR LCD DISPLAY

3,COLOR QUALITY:24 BIT REAL COLORS

4,EDGE ENHANCEMENT: OBJECT CONTOUR EDGE IS MORE DISTINCT

5,SUPER IMAGE ENHANCEMENT:   IMAGE DETAIL IS MORE DISTINCT

6,HIGH PENETRATE STRENGTH DISPLAY:   INCREASE BRIGHTNESS OF DARK AREA IN IMAGE TO DISPLAY OBJECT WHICH IS BEHIND HIGH ABSORPTIVITY MASS DISTINCTLY

7,LOW PENETRATE STRENGTH DISPLAY: INCREASE CONTRAST OF LOW ABSORPTIVITY MASS (EASY TO PENETRATE) TO DISPLAY IT DISTINCTLY

8,MAGNIFIER:  FUNCTION OF PARTIAL ENLARGEMENT

9,BRIGHTENING/DIMMING:   INCREASE BRIGHTNESS OF IMAGE/DECREASE BRICHTNESS OF IMAGE

10,IMAGE RECURRENCE:  DISPLAY PREVIOUS TWENTY IMAGES AND PROCESS ANY ONE OF THEM

11,IMAGE RESTORATION:  RESTORE IMAGE TO INITIAL STATUS AT THE TIME OF STOPPING CONVEYOR

12,IMAGE STORING:  REAL TIME STORE ANY IMAGE AND PROCESS IT IN OPERATION STATUS

MULTI-ENERGY FUNCTION

MULTI-ENERGY COLOR:

DISPLAY ORGANIC MATERIAL FOR ORANGE, DISPLAY INORGANIC MATERIAL FOR BLUE, AND DISPLAY MIXTURE FOR GREEN



HIGH ENERGY/LOW ENERCY:

SWITCH TO DISPLAY TWO ENERGY TYPE, HIGH ENERGY STANDS FOR METAL ETC., LOW ENERGE STANDS FOR NONMETALLIC



AUXILIAY FUNCTION FOR DRUGS & EXPLOSIVES:

HELP TO DETECT SUCH DANGEROUS MATERIAL AS DRUGS & EXPLOSIVES ETC.



AUDIBLE & VISIBLE ALARM:

GIVE SOUND AND VISIBLE SIGNAL WHEN CONFORMING TO CONDITION

OPERATING ENVIRONMENT

Storage Temperature:             -20ºC to 60ºC

Operating Temperature:           0ºC to 45ºC

Relative Humidity:               20 to 95% non-condensing

System Power:                  220 VAC (±10%) 50±3HZ

Power wastage:                1.0 KW (Max)

Noise:                        <65DB
