Technology Parameter:

Where WDS-620 can be used?
1. Watch / Mobile /Cell phone repair;

2. Notebook/ Laptop /Computer repair;

3. XBOX 360/PS2/ PS3/PS4 Wii and so on game console repair;

4. Othe SMD/SMT/IC BGA rework;

5. BGA VGA CPU GPU ECU and Car motherboard soldering desoldering;

6.BGA chips,QFP QFN chip,PC,PLCC PSP PSY rework.

Detailed images

Main Features

 Independent 3 heating zones temperature control system

1.The upper and lower hot air heating, which can heat up at the same time from the top of the component to the bottom of the PCB; bottom IR heating, temperature precision control within ±1℃.8 segment temperature control independently.

2.Hot air district heating for BGA and PCB at the same time, and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking, the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.

3.Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system;4 temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved; temperature can be tested precisely through external measurement interface, curves can be analyzed,set and correct on the touch screen at any time.

Precision optical alignment system

Using high definition and adjustable CCD color optical alignment system, beam split,amplification ,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment, adjustable image contrast; equipped with 15” high definition LCD monitor.

Multi-functional and humanized operation system

1.Adopting the HD touch human-machine interface; upper heating head and mounting head designed 2 in 1; providing many kinds of titanium alloy BGA nozzle can be rotated in 360 degree for easy installation and replacement.
2.X,Y and R angle adopted micrometer fine-tuning, accuracy locating, precision can reach ±0.01mm.WDS-620 infrared heating SMD Soldering Station phone repair machine with optical alignment system

Accessories of BGA machine

Workshop

We are Committed to producing a perfect machine!

Packaging & Shipping

1. Individual standard export wooden box for WDS  repair machine.

2. Delivery in 2 workdays after payment received.

3. Shipped by sea, by air or by express such as DHL, UPS, TNT, EMS etc.

4. Loading port: Shengzhen or Hongkong.

Machine Operation

Specific Repair steps:

1) Separate the BGA chip from mother board –we called desoldering
2) Clean Pad
3) Reballing  or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) Replace a new BGA chip - we called Soldering

Moreover:

Free training will be provided!
1.We will provide you English instruction book and Demo Video to see how to use.
2.About the temperature setting ,please refer to the setting of the temperature parameters manualhere and to see how to set temperature.
3.if you still have any question, please contact us by E-mail/phone call/Alibaba online service.

Our service and advantages

1.Your inquiry will be replied in 12 hours.
2.Original Manufacture to customers, with competitive price.
3.We provide one year warranty, free training and whole life technology support.
4.We can arrange the shipment by air, DHL,Fedex, UPS, and by Sea,etc for you, and will give you the tracking NO. after shipment.

5.Well-trained and Professional after-sales service team to support you.
6.Manual and Demo video CD will package with machine, It will show you how to use machine step by step.
7.Payment terms ,like T/T, Westerunion, PayPal is choosed by customers.

Pre-Sales Service:
* All productiong lines have adequate quality control and QA/QC inspectors work independently from the production line.All products passed CE & ISO certification.
After-Sales Service
* Offer free spare parts and service within 12 months of warranty,and all the other relative cost should be on the buyer's account.
* Provide Demo operation video for training.If you have time,welcome to our company,will arrange engineers to show you the operation,you can also test the machine by yourself.

If you need technical support for our products or any other problem,please contact  Jack Du by

Skype: jackdu85
Mobile:(+86) 186 8879 0572
WhatsApp/We Chat:+86-186 8879 0572

We will try to answer you with 12 hours
