1).OVERALL UNIT

Transmission box: special steel casting transmission

Main dimension(mm): L   2200 x W  970x H   1120

Wheelbase:(mm)      1150

Wheel tread:

front wheel(mm)  850

Rear-wheel(mm)  800

Mini-ground clearance(transmission bottom)  (mm)    200

Mini-turning circus  radius:(m)         2

Structural weight:(kg) 420

Theoretical speed:   km/h

First gear   2.24

second gear    3.48

third gear    5.62

First reverse gear   1.72

Second reverse gear    6.97

2) ENGINE MAIN SPECIFICATION

Engine model:   195 with starter, 12hp/16hp

Engine type: horizontal, single cylinder, four stroke

Rated turning speed:  r/min      2400

Rated power: 8.87 kw/12HP 11.8kw/16hp

Cooling type: diesel water cooled, with radiator (not Evaporative)

3).DRIVE SYSTEM

1.clutch      dry type, double , normally jointing and fricting type.

Final drive:    single stage spur gear transmission

3.differential:   support  conical planetary gear reducer with differential lock

4.transmission:   (3+1)*2 cylinder gear drive

5.brake:   external shoe type brake

6.drive type between engine and clutch: triangle belt

7.drive type between PTO and hydraulic pump :V-belt
