Ooitech 20w Fiber Laser Scribing Machine Solar cell laser cutting machine for crystalline solar cell cut
- Category: Laser Scribing >>>
- Supplier: Wuhan Ooi Photoelectric Technology Co. Ltd.
Share on (60062340661):
Product Overview
Description
Solar cell film laser scribing machine cutting machine
Product Description
[ Technical Parameters ] | |
Model | OLS-20F |
Laser wavelength | 1064nm |
Laser power | 20W |
Scribing width | 30μm |
Scribing speed | 200-300mm/s |
Scribing accuracy | ±10μm |
Working area | 245x245mm |
Temperature control precision | 0.5°C |
Working power | 220V/50Hz/1kvA |
Working table | negative pressure absorbing and dust elimination |
Cooling method | Forced air cooling |
Scribing or cutting the Solar Cells and Silicon Wafers in the solar PV industry, including the mono-si (monocrystalline silicon) and poly-si (polycrystalline silicon)solar cells and the silicon wafer.
1. Using the Germany IPG FIBER laser or China Raycus Fiber laser or Max fiber laser
service time over 100,000hours.
Stronger adaptability to the environment
better beam quality and higher speed than Diode Pump and YAG Krypton type.
No need to replace the laser module and Krypton lamp.
2. Worktable: X-Y movable
A solar cell can be automatic absorption
3. Air cooling, compact structure, small size
4. Higher conversion efficiency,
lower operating cost, save power consumption, cost and shorter maintenance time;
5. Laser Pulse width is more narrow,
Higher peak power, faster scribing cutting speed
6. Long-time uninterrupted continuous maintenance-free operation,
no consumable wearing parts to replace
7. Stepper motor or servo motor at different costs.
Packaging & Shipping
Company Information
FAQ
Q: Equipment Quality, Reliability Warranty?
1) Every machine in the detection process, through specialized testing equipment and facilities,
before machine out of our factory machine text 24 hours.
2) All of our machines have a 1-year quality Warranty from customers receive the machine. The company has built life-long correspondence files.
Q: Why choose us?
A: Doing business with Ooitech is SAFE and BENEFICIAL. Ooitech qualified Alibaba Trade Assurance
the project, Which means Alibaba will refund if there is any quality problem after your buying.
We are onsite checked by Alibaba. The supplier assessment report can be download on our company
profile site. A reliable supplier ensures the safety of your fund.CE and UL approved machines bring good
quality, and reasonable price helps you make profits from our machine.
Q: Do you have Training to Customer?
A: We will supply the machine operation manual in the English version.
For installation and operation, including introduction for the composing of equipment, working
principle of equipment, common knowledge of computers, controlling principle of electric devices,
daily maintenance measures of equipment. Personal demonstration for installation and adjusting
of equipment, operation of equipment, programming of the computer.
Users can dispatch representatives to our factory for 2-3 days for training. We are responsible for
training them free of charge. While all the charges including traveling charges and accommodation
will be afforded by the user.
Q: What are your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
