1PC 2000 WOG RB CARBON STEEL FORGED BALL VALVE FOR WATER OIL GAS
- Category: >>>
- Supplier: LUNG YUN CASTING CO. LTD.
Share on (60064638558):
Product Overview
Description
Product Description
Production Specification
Product Name | 1PC 2000 WOG RB CARBON STEEL FORGED BALL VALVE FOR WATER OIL GAS |
Model Number | BT-1C Ball Valve |
Pressure | 2000 psi 138 bar working pressure, |
Size Range | 1/4" to 2" |
Type of Port | Reduce Port |
Wall Thickness | ASME B16.34 |
Material | CF8, CF8M, WCB |
Ball | Stainless Steel |
Seat | PTFE, RPTFE |
Temperature | Max. 450°F |
Media | Water / Oil / Gas |
Connection | Screw End |
Thread confirm to | ANSI B1.20.1, BS21, DIN 259 / 2999 |
Type of thread | NPT, BSPT, BSPP, BSP, PT, DIN2999, DIN259, ISO228 |
Handle sleeve | According to customer requirements |
Features | 1. INVESTMENT CASTING 2. FLOATING BALL 3. BLOW-OUT PROOF STEM 4. LOCKING LEVER HANDLE 5. ANTI-STATIC DEVICE IS AVAILABLE 6. OEM / ODM Product |
Quality Inspection | Mill Certificate 3.1 and/or other per your request |
Pressure Test | API 598 |
Certification | ISO, CE, CRN, AD2000, API 607 5th Edition, NACE MR-0175 |
Lead Time | Based on the quantity, sample order available |
Terms | EX-WORK, FOB, CIF, C&F |
Payment | T/T, LC Before shipment for first order. |
Place of Origin | China / Taiwan |
Packing Information
Product Name | 1PC 2000 WOG RB CARBON STEEL FORGED BALL VALVE FOR WATER OIL GAS |
Valve Type | Ball Valve |
Label | As per customer’s request |
Packing method | CARTON, PLYWOOD PALLET, PLYWOOD CASE |
Delivery | Transport by Sea / Air / Express / Pickup |
Please send us your inquiry for more details. We will reply you within 24 hours.
Product Operation
There are many different methods to operate the valve according to different applications. We Lung Yun Casting can offer three different ways to operate the valves.
1) Manually operated valves: The valves can be operated manually by a handle, lever, pedal or wheel as showed on the pictures. We will suggest using manual operated valves due to small size, lower torque of the valve, safety environment or cost consideration.
2) Gear Operation: Based on high torque operation requirement, the gear operation system can help to control the valve easily. It will be applied to ball valves, gate valves, globe valves, butterfly valves, and other valves with larger size or high torque.
3) Actuated operation: For complex control systems or projects, the valves are requiring the automatic control. We also provide the actuated operation option such as electric motor actuator or pneumatic actuator. The connection for the actuator and valves is according to ISO5211 standard. Due to the application requirement for the valves, we have many different options of the actuator for you to choose. Please contact us or send us an inquiry for more details.
Our Services
Company Information
Profile
| Year | History |
|---|---|
| 1981, July | Established |
| 1981 | Manufacture Stainless Steel , Carbon Steel , Alloy Steel Motor Parts , various Industrial Machinery parts |
| 1985 | Manufacture Flanges |
| 1987 | Manufacture Trailer Parts |
| 1990 | Manufacture Stainless Steel & Carbon Steel Ball Valves and other valves |
| 1996 | ISO 9001 approved by DNV |
| 1999 | CRN approved. |
| 2003 | PED approved , CE approved |
| 2007 | Manufacture Sanitary Fittings |
| Fire Safe Approved of Class 1500,2500 Screwed Ends ball valves, Class 150 Flanged End Ball Valve | |
| 2011 | Setup machining shop |
| Fire Safe Approved of Forged Class 2500 Screwed Ends Full Port Ball Valve | |
| 2013 | Needle Valve, Pressure Reducing Regulator |
| 2014 coming | ADW 2000 W5 |
Certificate
Contact LungYun
Lung Yun Casting Co., Ltd
- www.lungyun.com
- lungyun.en.alibaba.com
- E-mail : inquiry(at)lungyun.com.tw
- No.20, Gong 3rd Rd., Dajia Dist., Taichung City 437, Taiwan
- Tel : +886-426817600
- Fax : +886-426813474 ; +886-426811817
- Foundry : Lung Yun Casting Co., Ltd No.63, Youshi Rd., Dajia Dist., Taichung City 437, Taiwan
- Tel : +886-426822260
- Fax : +886-426822262
