High Quality Low Price Heat Insulation Materials Calcium Silicate Board Xonotlite Insulation Board

Product Overview

Description



High Quality Low Price Heat Insulation Materials Calcium Silicate Board Xonotlite Insulation Board











1:Good durability, and can withstand high-temperature limit of the continuous thermal load



2:We obtained CE, KR and ISO9001



3:The highest heat resistance temperature is up to 1150 degree centigrade



4:The maximum flexural strength is up to 0.7MPa,all Technical Parameters are the best in China, it is better than other calcium silicate board in the market.



5 Our factory is corporate with the big power plant, uses the steam of the power plant to product the board, it is different from other factories to produce with the boiler. The product use the steam, the quality is better than use the boiler, so the technical parameters of our product are the best in factory. And it is very easy to mass product and reduce the waste, the cost is lower than our factory use boiler. So that the product from our factory is best quality and cheapest price.







High strength calcium silicate board
Item	Unit	Index value
Bulk Density	Kg/m³	600±10%
Flexural Strength	Mpa	≥5
Compressive Strength	Mpa	≥13
Thermal Conductivity	W/m.k	≤0.090+0.00011t
Temper Limit	℃	1050
Liner Shrinkage	%	≤2(1000℃,16hrs)





















Name	Calcium Silicate Board
Color	White
Main Market	Europe, Mid East ,Eastern Asia,South Asia,North America,other countries
Thickness	8 mm- 200 mm
Size	Maxizm size 1220mm*2440mm
Surface	Sanding or Non-Sanding Surface
WorkingTemperature	1150  °C
Component	Sio2 47% Cao 44%
Security	100% non-asbestos
Odour	odourless



Name	Calcium silicate board
Maximum size can reach up to 1220mm×2440mm length 2440mm width 1220mm
Standard Size  Of Calcium Silicate Board
Length  ( ±3mm )	Width  ( ±2mm )	Thickness   ( ±3mm,-1.5mm )
1260	1260\\610	25-120
1250	600	25-120
1200	600	25-120
1230	950	25-120
610	625\\300\\150\\100	25-140
600	300	25-140
400	250	25-140
1000	500	40-140
500	500	25-140
524	400	25-140
1080	950	25-140













1).Good durability and can withstand high-temperature limit of the continuous thermal load



2).Low thermal conductivity,in the whole scope of use is unmatched within the adiabatic Performance



3).Light weight,high stength,its strength is rigid insulation products in the highest



4).Durability,long-term use of ceramic fiber felt no similar powder



5).Construction practical,with ordinary tools can be arbitrarily cutting products



6).Used safety,hygiene,asbestos-free,sulfur,chlorine such poisonous substances





we have own factory to produce the boards, and we are not the trading company, so we would have the directly customer service and the warranty of our boards is very good!



We promise to all the customer, the customer service would be the best, and good warranty for all the product.













we have a agent in German, many German companies use our board, and the effects are very good. Our boards now is very popular in Gereman, USA, Russia and Arab ,South Korea and Japan market, many companies now uses our boards, and we also build a long relationship with this companies, and the corporate is very happily~



we have a very big factory and corporate with the big power plant to use the steam of the power station to product the calcium silicate board. It is better than other factory in China to produce with the boiler. Use the steam to product can reduce the product cost and improve the quality so our product is the best quality and the lowest price~







We have own factory to produce the boards, and we are not the trading company, so we would have the directly customer service and the warranty of our boards is very good! Our engineer Mr.Guo is very famous in this area, he has nearly 40 years working experience. and he has many patents in the calcium silicate board. i can promise the quality of our product is better than other factory.



My boss now is desired to open the oversea market, and he really want to build a long corporate relationship with the oversea company, so our factory now have a very good policy to give the oversea customer the lowest price.
