6 kpa pressure blower fan 12v centrifugal

                        Part Name:   6 kpa pressure blower fan 12v centrifugal  ;

                             Part No:  WS7040-24-V200;

                             Voltage:  24Vdc;

                      Max current:  2.6Amp;

              Free blow speed: 35000rpm;

Hall sensor electric Angle:  60 degree;

          Magnet poles pairs:  1 pole pair;

                       Resistance:  1.9 Ohms;

                       Inductance:  0.2mH;

                       Noise level:  65 dBA;

               Protection class:  IP20;

                 Max Pressure:  60cm H2O;

Current at Max pressure:  0.9 A;

                    Max Airflow:  260 LPM;

   Current at Max airflow:  2.6A;

       Sample Payment preference:  paypal /  bank account;

                   Sample delivery time:  3-5 days;

              Sample delivery method: Fedex, UPS, DHL;

                   Sample delivery cost: 20-45 USD for 1 kg;

           Mass Production payment:  Bank account;

     Mass production delivery time: 15-30 days;

Mass production delivery method:  Fedex, UPS, DHL, Ocean shipping;
