NSX type MCCB moulded case circuit breaker 160A MCCB

Product Overview

Description

NS TYPE MCCB

molded case circuit breaker



 Application:
NS  type MCCB series moulded case circuit breaker , it's applicable circuit of AC 50Hz(or 60Hz),ratedinsulation voltage 690V(OM3-125 500V),rated operating voltage AC 690V or below ,rated oper-ating current 12.5-1600A, for distribute energy of electric and infrequent making and breakingcircuit in normal condition. The circuit-breakers are provided with the function of the protectionagainst overload and short circuit and under-voltage. The circuit breakers comply with standardof IEC60947-2.The circuit-breakers are double insulating (Inm=250A or above), the controlcircuit of the accessories is set apart with the main circuit , and doesn't need to open the coverof the circuit-breaker when install the accessories .



Product performance:

Breaking capacity		B	N	S	H	X
Rated current of frame size      Inm		100
Rated current                         In		12.5,16,20,25, (30),32,40,50,(60),63,80,100,125,(150),160				12.5,16,20,25,32,40, 50,63,80,100,(125)
Rated insulation voltage            Ui		690V
Rated operating voltage            Ue		400V
Number of poles		3
Icu 400V/50HZ 0-CO  KA Rated ultimate short-circuit breaking capacity		20	35	50	50	70
Ics 400V/50HZ O-CO-COKARated service short-circuit breaking capacity		10	17.5	37.5	37.5	52.5
Icm 400V/50HZ 0-CO   KA Rated short-circuit making capacity		40/0.3	74/0.25	105/0.25	105/0.25	154
Uimp                     V Rated impulse withstand voltage		8000
Dielectric property                  V		3000
Endurance	Total cycles	8000
	Electrical endurance	1000
	Mechanical endurance	7000
Ionization distance                 (mm)		≤30/0
Over current trip unit	Thermal magnetic release
	Intelligent trip unit
Utilization category	Main circuit	A
	Auxiliary circuit	AC-15
Outline dimensions	W(mm)	90            90
	L(mm)	120            120
	H(mm)	70              82
