Acid Resistant Stainless Steel Full Port 2 pc Threaded 1000 WOG Full Weld Sanitary Ball Valve
- Category: >>>
- Supplier: LUNG YUN CASTING CO. LTD.
Share on (60083192022):
Product Overview
Description
Product Description
Production Specification
Product Name | TWO PIECES STAINLESS STEEL FULL PORT 1000 WOG BALL VALVE BALLS DWG |
Model Number | 2PC 1000PSI Ball Valve |
Pressure | 1000 psi 69 bar working pressure, |
Size Range | 1/4" to 2" |
Type of Port | Full Port |
Wall Thickness | ASME B16.34 |
Material | WCB, CF8, CF8M |
Ball | Stainless Steel |
Seat | PTFE, RPTFE or as per your request |
Temperature | Max. 400°F |
Media | Water / Oil / Gas |
Connection | Screw End |
Thread confirm to | ANSI B1.20.1, BS21, DIN 259 / 2999 |
Type of thread | NPT, BSPT, BSPP, BSP, PT, DIN2999, DIN259, ISO228 |
Handle sleeve | According to customer requirements |
Features | 1. INVESTMENT CASTING 2. FLOATING BALL 3. BLOW-OUT PROOF STEM 4. LOCKING LEVER HANDLE 5. ANTI-STATIC DEVICE IS AVAILABLE 6. OEM / ODM Product |
Quality Inspection | Mill Certificate 3.1 and/or other per your request |
Pressure Test | API 598 |
Certification | ISO, CE, CRN, AD2000, API 607 5th Edition, NACE MR-0175 |
Lead Time | Based on the quantity, sample order available |
Terms | EX-WORK, FOB, CIF, C&F |
Payment | T/T, LC Before shipment for first order. |
Place of Origin | China / Taiwan |
Packing Information
Product Name | TWO PIECES STAINLESS STEEL FULL PORT 1000 WOG BALL VALVE BALLS DWG |
Valve Type | Ball Valve |
Label | As per customer’s request |
Packing method | CARTON, PLYWOOD PALLET, PLYWOOD CASE |
Delivery | Transport by Sea / Air / Express / Pickup |
Please send us your inquiry for more details. We will reply you within 24 hours.
Our Services
Company Information
Profile
| Year | History |
|---|---|
| 1981, July | Established |
| 1981 | Manufacture Stainless Steel , Carbon Steel , Alloy Steel Motor Parts , various Industrial Machinery parts |
| 1985 | Manufacture Flanges |
| 1987 | Manufacture Trailer Parts |
| 1990 | Manufacture Stainless Steel & Carbon Steel Ball Valves and other valves |
| 1996 | ISO 9001 approved by DNV |
| 1999 | CRN approved. |
| 2003 | PED approved , CE approved |
| 2007 | Manufacture Sanitary Fittings |
| Fire Safe Approved of Class 1500,2500 Screwed Ends ball valves, Class 150 Flanged End Ball Valve | |
| 2011 | Setup machining shop |
| Fire Safe Approved of Forged Class 2500 Screwed Ends Full Port Ball Valve | |
| 2013 | Needle Valve, Pressure Reducing Regulator |
| 2014 coming | ADW 2000 W5 |
Certificate
Contact LungYun
Lung Yun Casting Co., Ltd
- www.lungyun.com
- lungyun.en.alibaba.com
- E-mail : inquiry(at)lungyun.com.tw
- No.20, Gong 3rd Rd., Dajia Dist., Taichung City 437, Taiwan
- Tel : +886-426817600
- Fax : +886-426813474 ; +886-426811817
- Foundry : Lung Yun Casting Co., Ltd No.63, Youshi Rd., Dajia Dist., Taichung City 437, Taiwan
- Tel : +886-426822260
- Fax : +886-426822262
