Hydraulic lift car elevator auto hoist vehicle lifting

 Main Technical Parameter

Model: QJY-S3

Capacity: 2700KG

Lifting Height: 1400mm

Min. Height: 180mm

Outer Dinensions: 2550x1000x180mm

Power: 380v/ 220v

Net Weight: 450KG

---------------Features---------------

1. Manual single side release


2. 24V power control box for choice guards against unexpected hurt or jury


3. Lifting height 1400mm, used for quick tire replacement and simple service


4. Adjustable lifting pads suitable for more types of vehicles


5. It has been proofed by dynamic test with 125% of rated capacity and static test with 150% of rated capacity


6. CE approved

1.Does my lift come with the necessary anchor bolts and/or hardware to mount it to the floor?
All JIUYA lifts ship with the necessary anchors required for mounting the unit to your floor.

2.Does hydraulic fluid come with the lifts?
Due to current DOT and insurance laws regarding the transport of hydraulic oils (DOT Section 1 - Hazardous Ingredients; DOT Section 2 - Fire and Explosion Hazards and DOT Section 3 - Health Hazards) the required hydraulic fluid is to be supplied by the end-user, only. JIUYA lifts are designed to operate using standard 10-weight, non-foaming, non-detergent hydraulic oil or Dexron-III ATF fluid. This is available in virtually any automotive store.

3.Do I need a special floor or foundation to support my new lift?
Most residential or commercial foundations are strong enough to support JIUYA lifts. However, it is important to adhere to concrete specifications. Failure to do so could cause lift failure resulting in personal injury or death.

A level floor is suggested for proper installation and level lifting. With proper shimming, small differences in floor slopes may be compensated for. If a floor is of questionable slope, consider a survey of the site and / or the possibility of pouring a new level concrete slab.

4.What is the ceiling height required for a JIUYA lift?
The required ceiling height will vary depending on the lift model, as well as the intended vehicle. Please refer to the product specification page for each product for further details. Or contact us for advice.

5.Do car lifts require maintenance?
A simple monthly checklist is perhaps the most you'll do on a regular basis, aside from common-sense visual inspections you'll do every time you lift and lower your vehicles. Cables need to be maintained, as do hydraulic systems. Because JIUYA sells in such high volume, replacement parts (and therefore the cost of owning a JIUYA car lift) are much less than the cost of owning other brands' lifts.

6.Are car lifts available in different voltages?
Other (unlisted) voltages may be available upon request. Voltage options vary between models.
