soft flexible PE foam sheets , pe foam blocks with white and charcoal color
- Category: >>>
- Supplier: Shijiazhuang Qihong New Material Products Co. Ltd. [Hebei China]Shijiazhuang
Share on (60085067078):
Product Overview
Description
soft flexible PE foam sheets or pe foam blocks with white and charcoal color
Product Description
Name: PE Foam Sheets, blocks
Other Name: PE Foam, polyethylene foam.
Density: 20kg/m3, 30kg/m3, 45kgm3, 64kg, 90kg, 120kgs
Hardness: 15-60 Shore C
Color: White or black
Size: 2000 mm x 1000 mm
Thickness: 2-300 mm
Customized sizes and shape available
Product technical date sheet of soft foam others to be available on request:
Properties | Unit | L-4500 | Test Method |
Density | KG/M3 | 20 ± 3 | GB/T6343-2008 |
Hardness | Shore C | 11 – 16 | —— |
Elongation Ratio | % | 100 Min | GB/T6344-2008 |
Compression Set | % | 15 Max | GB/T6669-2008 |
Linear Shrinkage | % | ± 5 | GB/T8811-2008 |
Tensile Strength | kPa | 130 Min | GB/T6344-2008 |
Tear Strength | KG/cm2 | 5 v | GB/T10808-2006 |
Water Absorption | gm/cm3 | 0.005 Max | GB/T1034-2008 |
Compression Strength | KG/cm2 | 0.2 Min | GB/T8813-2008 |
Working Temperature | Degree | -40 to 70 | —— |
Thermal Conductivity | W/m.k. | 0.038 Max | GB/T3399-1982 |
Application:
Heat insulation material, packing materials, cushion, gasket,etc.
Products lists.
Products | Our types | Density | Block Size (mm) | Hardness Shore C | Typical use | ||
PE Foam blocks | L-4500 | 20 kg/m3 | 2000x1000x100 | 12-17 | Heat insulation | ||
L-3500 | 27 kg/m3 | 2000x1000x90 | 15-20 | Cushioning | |||
L-2500 | 40 kg/m3 | 1250x2480x102mm | 27-32 | Package inserts | |||
L-3000 | 30 kg/m3 | 2000x1000x90 1250x2480x102mm | 20-27 | Floating mateiral | |||
L-2000 | 45 kg/m3 | 2000x1000x90 | 30-38 | Box insert for tool | |||
L-1700 | 60KG/m3 | 1250x2480x102mm | 37-42 | Filler foam | |||
L-1000 | 90 kg/m3 | 2000x1000x50 | 47-52 | Underlay | |||
L-1100 rough cell | 80 kg/m3 | 2000x1000x50 | 47-52 | joint filler foam | |||
L-600 rough cell | 120 kg/m3 | 2000x1000x50 | 55-65 | Water project filler | |||
EVA Foam block | S-3000 | 30 kg/m3 | 2000x1000x90 | 12-17 | Cushioning, filler | ||
S-2000 | 50kg/m3 | 2000x1000x90 | 20-25 | Package, Sports, | |||
S-1000 | 90 kg/m3 | 2000x1000x50 | 37-42 | Sports, mats | |||
Fire resistant grade for options |
|
|
|
| |||
Rubber Foam | Grade | density | Size in mm | Hardness |
| ||
EPDM0815 | EPDM0815 | 110kg/m3 | 1800x900x50 | 8-15 | Cushioning, pads | ||
EPDM Foam | EPDM2025 | 130kg/m3 | 2000x1000x50 | 20-25 | Gasket, sealant | ||
EPDM3540 | 180kg/m3 | 2000x1000x30 | 35-40 | Gasket, base | |||
CR Foam | CR2025 | 150kg/m3 | 2000x1000x50 | 20-25 | Gasket, sealant | ||
Other material | Plastezote, | EVA ZOTE | XPE, IXPE | PU foam | NBR foam | ||
Further cutting Processing Finished doing | 1. Normal cut, spliting 2. laminate to thicker sheet, 3. die cut , mold cuts, CNC milling, wire cuts 4. special shaped making 5. back with glue , paper, Non skids, foil, textures 6. logos, printings ,
| ||||||
