Singer 300U Sewing Head Tape Edge Closing Machine for Mattress
- Category: >>>
- Supplier: Shenzhen Maps Industry Co. Ltd.
Share on (60086489882):
Product Overview
Description
Singer 300U Sewing Head Tape Edge Closing Machine for Mattress
1. Brief Introduction
This machine is mainly used for the production of mattress,Sewing up the front surface fabric and wall cloth. It can also be used for sewing as soft mattresses, soft pads for sofa and sleeping bag. It is equipped with the hanging rotary power supply, enabling it to rotate and sew continuously. It can work at any fixed point within its sewing track. The sewing speed and procedure can be controlled by the knee lever.
2. Specifications
Model | AV-206 | AV-206E |
Turning Sewing Speed(at corner) | Yes | No |
Sewing head form | lock stitch | lock stitch |
Working angle of head | 35-55° | 35-55° |
Lift of table(adjustable) | automatic | manual |
Sewing head speed | 1100-3000r/min | 1100-3000r/min |
Carriage travelling speed | 5.5-16r/min | 5.5-16r/min |
Power | 1.5kw | 1.5kw |
Available mattress height | 50-300mm, 150-400mm, 250-500mm | |
Table size | 1400*1950mm, 1550*2050mm, 1800*1950mm | |
3. Guarantee & After-sale Service
- One year guarantee for whole machine.
- 24 hour technical support by email.
- Door-to-door service available.
- English manuals.
4. Packaging & Shipping
1) Packaging: packing by EPE & Stretch film first, then packing by wooden cases, with exported standard, to avoid any damage to the machine during transportation.
2) Shipping: by sea or air. According to customers' choices.
5. Product Pictures
6. Factory
1) Own factory and professional R&D team.
2) 10 years experience, the most competitive price and best quality.
3) Main products have CE certificate.
4) Rapid on-site solutions, adopt Simens motor, PLC controlling system and electronic weighting system.
5) The best technical support and after-sales service.
7. Exhibitions & Honor
