2015 led5 video wall oled screen leddancef p4 indoor open signs

Product Overview

Description

Alibaba express indoor P4 SMD stage full color led video display

	The technology parameter of P4 indoor
	Item	P4
1	Pixel pitch	4mm
2	Size of unit board	128mm X 128mm
3	Resolution of unit board	32 X 32
4	Density of pixel	62500dots/m2
5	Pixel configuration	1R1G1B
6	Red wavelength	625±2nm
7	Green wavelength	525±2nm
8	Blue wavelength	470±2nm
9	Colors	16777216
10	Best viewing distance	≥4m
11	Horizontal viewing angle	140°
12	Maximum power consumption	≤600W/m2
13	Brightness	1800-2200cd /m2
14	Gray scale	16bits per color
15	Color temperature	6500k
16	Control method	Synchronization & Asynchronization
17	Driving method	1/16 or 1/8 scanning
18	Frame frequency	60Hz
19	Refresh frequency	350Hz
20	Working voltage	AC220V/110V±10%
21	IP grade	IP20~IP65(adjustable)
22	Working temperature	-20°C~80°C
23	MTBF	>10000 hours
24	Life span	>100,000 hours
25	Computer operation system	Win XP/Vista/ Win 2000/WIN7ect.
26	Video signal	RF, S-Video, RGB, RGBHV, YUV, YC.ect









Package: Carton box/Wooden case/Flight case optional



Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.OEM&ODM,any your customized lightings we can help you to design and put into product
3.Distributoership are offered for your unique design and some our current models
4.Protection of your sales area,ideas of design and all your private information
5.Top Quality+Reasonable Price+Responsible After Service=Successful & Win

6. our engineer will be on your service.We can give you technology support at any time.

7. We will be tracking your orders, from the pre-sale to the after-sale and also serve you in this process.

8.We can send our engineer to install the screen freely if you requested.



Trade Terms
1.Payment:L/C,western union,Paypal.T/T,30% deposits before production,70% balance to be paid before deliverying.ETC.
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm
