self bonding magnet copper wire for rewinding of motors
- Category: >>>
- Supplier: Dongguan Huaye Cables Technology Co. Ltd.
Share on (60092716638):
Product Overview
Description
Product Description
Industrial machinery Magnet copper wire,self bonding,varnish lacquered enamel copper wire,direct soldering,155class,round
Industrial machinery Selfbonding solderable enamel magnet wire
Brand name | HUAYE | Specification Met | MW 131 C |
Material type | copper wire | Application | coils winding |
Bare copper dia. | 0.018-0.70mm (awg 21-46) | Finish | Enamel |
Thermal class | 155 /180 Degrees celsius | Shape | Round |
Bond method | solvent or heat bonding | Color | natural or according to requirements |
Spool | PT-15,PT-10.PT-4,PL-2,PC-1 | Certification | UL,SGS,REACH,ROHS |
Enamel Base coat | mod. Polyurethane | Enamel Bond overcoat | Self bonding Polyamide(nylon) |
Certificate:
Production Flow:
Application: generators and electrical controls
self-bonding inductance coils:
Inductance coils, magnetic coils of products such as toys, sensors,laser magnetic heads, chip inductors,clocks, high frequency magnetic core transformers, communications networks.
voice coils:
All kinds of trumpet voice coils.
general motors coils:
Motor coils such as electric motors, servo motors, submersiblepump motors, draining
pump motors, brushless motors, transformers and motors in cars.
small motors coils:
Small vibration motors(flat,columnar) coils: telephone motors, toys motors, airplane model
motors, small household appliances motors.
contactless IC card coils:
13.56MHz contactless IC card coils, compatible with internal antenna of CPU.
smart card(ID)antenna coils:
Apply to all kinds of smart card antenna coils.
Low frequency 125 KHz, high frequency13.56MHz, ultrahigh frequency2.5GHz and
different shapes of card coils.
high-performance magnetic induction coils:
Apply to magnetic induction equipment of motors illumination, security, wireless
charging and so on, such as infrared induction floor, mobile wireless charging.
Properties:
Imported high quality copper and environmental protection enamel are adopted in the series of the
products to improve tensile strength and uniformity of the film.
Stable impedance, uniform diameter, good electrical performance are always kept and resistance
to high-temperature, wear and corrosion have further promoted in order to guarantee the wonderful
effect of bonding and range, bright and clean surface.
It fits the harsh environment of special motors and meets the requirements of the times for it has
replaced the varnishing process and improved its environmental protection level.
Characteristic:
Our Services
1.Quality assured, refund guarantee due to quality issue
2.Free sample
3.Factory direct price
4.Shipping on time
Packaging & Shipping
Packing: Inner packing: Plastic Spool of PT-15,PT-10.PT-4,PL-2,PC-1 according to wire size
Outer packing: Carton box and styrofoam or as customer required
Shipping: Sample time: Nearby 3-5days, distance 5-7days. Production time: 7-30days
FAQ
1.What kind of copper wire do HUAYE produce?
We focus on research and development of self-bonding magnet round copper wire, fine polyurethane magnet wire, self-bonding litz copper wire and self-bonding silk covered wire.
2.What's diameters available of the products?
We specialize in fine and ultra fine enamelled copper wire,diameters available of our products is Φ0.018-0.50mm.
3.What's self-bonding enamelled copper wire?
Self-bonding enamelled copper wire is a special type of enamelled wire with an additional adhesive enamel overcoat such as thermoplastic resin.
This adhesive has a bonding feature, which is activated by heat or solvents.
Once activated the adhesive bonds turn to turn windings into a compact self supporting coil.
The use of selfbonding wire may offer cost and manufacturing advantages in some winding applications
as bobbins, tape, varnishing, or impregnation may be eliminated.
4. Is possible to get any sample of selfbonding enamelled copper wire that you have in production?
Of course you can!
Company Information
Company Idea: Sincere Trust Unite Create Share
Dongguan Huaye Cables Technology Co.,Ltd was founded in 2003 .
We focus on research and development of self-bonding magnet round copper wire, fine
polyurethane magnet wire,litz copper wire and self-bonding silk covered wire.
Diameters available of our products is Φ0.018-0.50mm
Our annual production capacity reaches to 800-1200 tons.
Huaye insist that “Quality is the foundation of value and respect” .
We are confident that all clients’ requirements are guaranteed.
