NES 150 switching power source 150W 48V smps
- Category: >>>
- Supplier: Yueqing Wode Electrical Co. Ltd.
Share on (60104514914):
Product Overview
Description
Product Description
NES-150 switching power source 150W 48V smps
Features
1.High Efficiency and good price
2.Built-in EMI filter
3.100% full load burn-in test
4.Low output ripple and noise
5.Protection:Over load/Over voltage/Short circuit
6.LIFETIME WARRANTY
Specifications
| MODEL | NES-150-5 | NES-150-12 | NES-150-15 | NES-150-24 | NES-150-48 | |
| OUTPUT | DC VOLTAGE | 5V | 12V | 15V | 24V | 48V |
| RATED CURRENT | 26A | 12.5A | 10A | 6.5A | 3.3A | |
| CURRENT RANGE | 0 ~26A | 0 ~ 12.5A | 0 ~ 10A | 0 ~ 6.5A | 0~ 3.3A | |
| RATED POWER | 130W | 150W | 150W | 156W | 158.4W | |
| RIPPLE & NOISE (max.) | 80mVp-p | 120mVp-p | 120mVp-p | 120mVp-p | 200mVp-p | |
| VOLTAGE ADJ. RANGE | 4.75~5.5V | 11.4~13.5V | 14.25~16.5V | 22.8~27.6V | 45.6~52.8V | |
| VOLTAGE TOLERANCE | ±2.0% | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| LINE REGULATION | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| LOAD REGULATION | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| SETUP, RISE TIME | 800ms,30ms/230VAC 1200ms,30ms/115VAC at full load | |||||
| HOLD TIME | 24ms/230VAC 10ms/115VAC at full load | |||||
| INPUT | VOLTAGE RANGE | 90~132VAC/180~264VAC selected by switch 254~373VDC | ||||
| FREQUENCY RANGE | 47 ~ 63Hz | |||||
| EFFICIENCY (Typ.) | 78% | 83% | 83% | 86% | 86% | |
| AC CURRENT | 3A/115VAC 2A/230VAC | |||||
| INRUSH CURRENT (max.) | Cold Start 45A/230VAC | |||||
| LEAKAGE CURRENT | <2mA/240VAC | |||||
| PROTECTION | OVERLOAD | 110~150% rated output power | ||||
| Protection type : Constant current limiting, recovers automatically after fault condition is removed | ||||||
| OVER VOLTAGE | 5.75~6.75V | 13.8~16.2V | 17.25~20.25V | 27.6~32.4V | 55.2~64.8V | |
| Protection type :Shut off | ||||||
| ENVIRONMENT | WORKING TEMP. | -20 ~ +60°C | ||||
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing | |||||
| STORAGE TEMP., HUMIDITY | -40 ~ +85°C, 10 ~ 95% RH | |||||
| TEMP. COEFFICIENT | ±0.02%/ (0 ~ 40°C) | |||||
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min | |||||
| SAFETY & EMC | SAFETY STANDARDS | Desgin refer to UL1012,EN60950-1,EN61347-1,EN-61347-2 approved | ||||
| WITHSTAND VOLTAGE | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |||||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | |||||
| EMC EMISSION & IMMUNITY | EN55015,EN55022,EN55024,EN61000-2,EN61000-3,EN61547 approved | |||||
| OTHERS | MTBF | ≥400K hrs min | ||||
| DIMENSION | 199×98×38mm (L*W*H) 0.7kg | |||||
Packaging & Shipping
Our Services
We are the only supplier in Alibaba can provide LIFETIME WARRANTY power supply,please don't be hesitate to check with our Ali web://wodecn.en.alibaba.com/ and contact us by TradeManager or Skype for more details(our TM ID is wodecn and Skype ID is wode.smps).
