5 gallon Filling Machine
Production Introduction:
5 gallon filling machine,automatic barrel filling machine,5 gallon filling line,barrel filling machine ,filling machine,filling equipment,filling and sealing machine
This filling line specially produces 5 gallons bottled drinking water,whose types(b/h)are:100 type,200type,300type,450 type,600type,900 type,1200type and 2000 type.ltintegrates bottle washer,filler andsealer into one unit,in order toachieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and leaching areused in bottle washer,Washing solution can boused circularly.The sealer can seal bottle caps automatically.This line equips with water spraying device tosterilize caps of bottlesin order to ensure those caps are aseptic and healthy,also this line can automatically carry out bottle feeding washing,sterilizing,filling capping,counting and products discharging.It is a new kind of barreled water auto-producting line,which integrates mechanism,electricity and pneumatics technologies together.

Technical Parameters:
| Model | QGF-150 | QGF-300 | QGF-450 | QGF-600 | QGF-1200 | QGF-1500 | QGF-1800 |
| Filling heads | 1 | 2 | 3 | 4 | 8 | 10 | 12 |
| (L)Volume | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| (mm)barrel size | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 | 270*490 |
| (b/n)Capacity | 150 | 300 | 450 | 600 | 1200 | 1500 | 1800 |
| (Mpa)Gas pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
(m3min) Gas consumption | 0.37 | 0.67 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| (kw)Moto power | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| (V)Rated Voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| (kg)Weight | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500 |

Zhangjiagang Keyuan Machinery Co., Ltd. is a professional food and beverage machinery manufacturer. Keyuan has its own special advantages in the research, design and manufacture, and offers technical support to customers. We also provide perfect after-sales service.
Our Beverage Machinery includes carbonated soft drink production lines; non-aerated beverage bottled filling production lines and juice/tea beverage/wine bottled/barreled filling production lines. You are welcome to cooperate with us.
What we supplies:
Middle and small size mineral water and pure water canned production lines. The output is 2,000 to 36,000 BPH
Juice and tea beverage machinery hot filling production lines. The output is 2,000 to 36,000 BPH
Carbonated beverage machinery processing and filling production line. The output is 2,000 to 30,000 BPH
Soy sauce, vinegar, edible oil filling production line. The output is 2,000-12,000 one hour.
3, 5-gallon barreled drinking water production line. The output is 60 -1200 barrels one hour.
One gallon bottled drinking water production line. The output is 600-1200 bottles one hour.
Soy milk, peanut milk beverage (machinery) production line. The output is 0.5-20T one hour.
Compound fruit and vegetable juice/powder processing equipment. The output is 1 to 20 tons one hour.
Edible oil exclusive packaging production lines.
Beverage machinery preprocessing equipment.
Water treatment (mineral water, purified water, food process water) equipment. The output is 2-20T one hour.
Related equipment: bottle unscrambler, reversing bottle machine, spraying cold machine, enrichment equipment, CIP cleaning machine, UHT instantaneous sterilizer, labeling machine, blow molding machine


Before Sales
1.Answer your any question on us with in 24 hours.
2.Supply all information you required.
3.Machines video for reference.
4.Welcome to visit factory.

After Sales
1.Update production progress each week.
2.Sending machines pictures on production .
3.Machines testing running over 8 hours, and sending testing videos.
1) Can your factory provide the whole plant from A to Z?
A: Yes, we can provide the complete plant, from bottling making plant, water purification plant, to filling packing plant.
2) Are all machinery your factory made?
A: Our factory make the water purification and filling packing plants. We do not make the bottle making machinery,
we have good quality bottle making machinery partner, and we provide to customer same long warranty time and good after service.
3) How can I know the machinery quality before I order?
A: Frist, we will invite you visiting our factory to check the machines quality, and show the machines running for you in our factory.
4)What certificates you can provide?
A: Our factory provide the CE, ISO, and accroding to some countries, we also can provide the Pvoc, Coc, Soncap...ect
5)Can your factory make the bottle drawing, workshop layout, and labels for us?
A: We can help customers design their own bottle shape, workshop layout and label drawings, these jobs are free charge.
(Workshop need customer to provide the size of factory)
6)Installation and Training Time
A: We have professional engineer for oversea installaion and training, they can speak English, and have much experience oversea work.
Welcome to visit our factory!!!
