Tensile membrane structures

Product Overview

Description

Tensile membrane structures



Feature



1,High strength and intensity but light weight
2,Waterproof, UV resistance, heat insulation,anti-aging, Transmittance  ect.

3,Moisture proof, smoke proof, soundproof self-cleaning, beautiful view
4,Modern design, Easy to install

5, used in seasonal or permanent structures for indoor sports and recreational facilities as gymnasiums,

stadiums, swimming pools, cafeterias and food courts, exhibition and conventional

centers, canopies and vehicle parkings, etc



Dimension and Formation



Plan	Side Elevation	Axonometric View





Standard size :



Product Description	Side Length	Eave Length	Total Height	Projected Area
W9000-B-1	4 m	2.2 m	3.6 m	16 m2
W9000-B-2	5 m	2.6 m	4.4 m	25 m2
W9000-B-3	6 m	3.0 m	5.2 m	36 m2



Technical and material Description



• Design according to: Technical specifications for membrane structures (CECS 158-2004), code for      design of steel structure (GB50017-2003).
• Design Date:The limit of wind speed for safe use is 80Km/h; the limit of snow load is 10 cm.
• Steel work: Anti-rust treatment of ball blast and painting for Q235 steel; galvanized steel cables coated by PE and suppressed anchorage; galvanized bolts
• Membrane and color(M): Membrane T- White PTFE membrane from Europe; Membrane W - Architectural PVC from Europe (Standard is white and others refer to color card)
• Other notes: Flexible height of outer eave.
