PA meterial electrical cable chain plastic carrier
- Category: >>>
- Supplier: Dongguan City Junhong Tube Co. Ltd.
Share on (60107176135):
Product Overview
Description
Specification
MATERIAL | PA66(NYLON) |
INNER HEIGHT | 18mm |
INNER WIDTH | 18mm,25mm,37mm |
RADIUS | 38mm |
OUTER HEIGHT | 24mm |
OUTER WIDTH | INNER WIDTH+13mm |
Product Paramenters
Installation Instructions
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1.For better for shipping,the Chain will be packing as 1 meter each piece and we will let you know how to connect.
2.All the chain with our logo.IF YOU WANT PRINT YOUR LOGO ON THE CHAIN,pls let me know.
3.All of our size really in stock,THE MOQ ONLY ONE METER EACH SIZE.
4.THERE ARE CLOSED TYPE,BRIDGE TYPE and SEMI CLOSED TYPE.
5.IF THE SIZE YOU NEED NOT in THE BELOW FORM,PLS LET ME KNOW,MOST OF THE POPULAR SIZE WE HAVE
More Sizes
Inner Height | Inner Widht(Choice) | Radius(Choice) |
7mm | 7mm | 28mm |
10mm | 10mm,15mm,20mm | 28mm,38mm |
15mm | 18mm,20mm,30mm | 28mm,38mm |
18mm | 18mm,25mm,37mm | 38mm |
20mm(Light) | 25mm,52mm | 38mm |
20mm | 25mm,38mm,50mm,60mm,75mm,100mm | 55mm,75mm,100mm |
25mm(Light) | 38mm,57mm,77mm | 55mm,75mm |
25mm | 25mm,38mm,50mm,60mm,75mm,100mm | 55mm,75mm,100mm,125mm,150mm |
30mm | 25mm,38mm,50mm,60mm,75mm,100mm | 75mm,100mm,125mm,150mm,175mm |
35mm | 50mm,60mm,75mm,100mm,125mm,150mm,175mm,200 | 100mm,125mm,150mm,175mm,200mm |
45mm | 50mm,60mm,75mm,100mm,125mm,150mm,175mm,200 | 100mm,125mm,150mm,175mm,200mm |
55mm | 50mm,60mm,75mm,100mm,125mm,150mm,175mm,200 | 125mm,150mm,175mm,200mm,250,300 |
65mm | 50mm,60mm,75mm,100mm,125mm,150mm,175mm,200 | 125mm,150mm,175mm,200mm,250,300 |
80mm | 75mm,100mm,125mm,150mm,175mm,200mm,250,300 | 150mm,175mm,200mm,250mm,300mm |
