Blue Selective Coating Flat Plate Solar Collector Laser Welding
- Category: Solar Collectors >>>
- Supplier: Zhejiang,Shentai,Solar,Energy,Co.,Ltd.
Share on:
Product Overview
Description
Product Category
Product Show
Collector Absorber
Cover: mistlite low iron extra clear tempered glass Surface: Eta plus coating
Thickness of cover: 3.2mm Thickness: 0.12mm-0.4mm
Header pipe: Φ22mm (thickness: 0.8mm) Abosorber emittance: 5%±2% (Eta Plus)
Riser: Φ10mm (thickness: 0.7mm) Abosorber absorption: 95%±2% (Eta Plus)
No. of risers: 8 Connection between pipes & absorber: laser welding
Distance between pipes: 110mm
Liquid heat transfer: water or anti-freeze fluid (water-glycol)
Specifications
| cover | mistlite low iron extra clear tempered glass |
| thickness of cover | 3.2mm |
| header pipe | Φ22mm (thickness: 0.8mm) |
| riser | Φ10mm (thickness: 0.7mm) |
| No. of risers | 8 |
Distance between pipes | 110mm |
Liquid heat transfer | water or anti-freeze fluid (water-glycol) |
Surface | nti-freezing > -35 degree |
| Thickness | 0.12mm-0.4mm |
| Abosorber emittance | 5%±2% (Eta Plus) |
| Abosorber absorption | 95%±2% (Eta Plus) |
| Connection between pipes & absorber | laser welding |
Series Products
| Models | L*W*H mm | Welding | Riser | Capacity (liter/daily/60℃)
| Effective collector area m2 | GW (kg) | Qty(set) | |||||||||
| 20'FT | 40'HQ | |||||||||||||||
| SP2.0-A | 2000*1000*78 | laser | blue selective | 100L-130L | 2 | 27 | 100 | 220 | ||||||||
| SP2.0-B | 2000*1000*78 | laser | black selective | 100L-120L | 2 | 27 | 100 | 220 | ||||||||
| SP2.0 | 2000*1000*78 | laser | blue selective | 100L-130L | 2 | 28 | 100 | 220 | ||||||||
Trade Terms
| Payment | T/T with 30% deposit, balance against the copy of B/L 100% T/T in advance for sample |
| MOQ | 1 Set |
| Loading port | Shanghai / Ningbo |
| Package | Standard carton |
| Delivery | 7-10 days after payment for sample 15-20 days after payment for container |
Package & Shipping
Exhibition
Contact Us
Company Name: Zhejiang Shentai Solar Energy Co., Ltd
Address: No.199 Lianhong Road, Yuanhua Industry Zone, Haining City, Zhejiang Province, China
TEL: 0086-573-87861111 FAX: 0086-573-87862577
Website: www.suntasksolar.com
Thank you for taking time to visit our website , if you want to know more about factory and us , please contact us
