mini 3 position slide switch 8 pin push handle switch micro switch
mini 3 position slide switch 8 pin push handle switch micro switch
mini 3 position slide switch 8 pin push handle switch micro switch
mini 3 position slide switch 8 pin push handle switch micro switch
mini 3 position slide switch 8 pin push handle switch micro switch
mini 3 position slide switch 8 pin push handle switch micro switch
mini 3 position slide switch 8 pin push handle switch micro switch

mini 3 position slide switch 8 pin push handle switch micro switch

Share on (60109333123):


Price:$0.05 - $0.07

Quantity:


Product Overview

Description





Rated Current
50mA MAX
Rated Voltage
DC 12V
Contact Resistance
≤70mΩ
Insulation Resistance
≥100mΩ
Comressive Strength
AC250V  50Hz/1 min
Operating Force
150±50gf
Mechanical Life
10000 cycles min
Operaating Stroke
2.2±0.2mm
Temperature Range
-30℃~85℃
