green energy 2 ton pyrolysis machine with best price

Model

Reactor size

Weight

Volume

Space required

Capacity

Note

XD/05

2.0m*5.0m

27t

22m³

80m²-100m²

5T/Batch

3batch/2days

XD/06

2.2m*6.0m

30t

23m³

100m²-120m²

6T/Batch

3batch/2days

XD/08

2.2m*6.6m

32t

25m³

150m²

8T/Batch

1batch/1days

XD/10

2.6m*6.6m

38t

35m³

150m²-200m²

10T/Batch

1batch/1days

XD/12

2.8m*6.6m

40t

40m³

150m²-200m²

12T/Batch

1batch/1days

Model

Feeding time

Processing time

Cooling time

Carbon discharge time

XD/05

1-2hrs

6-8hrs

2hrs

1-2hrs

XD/06

1-2hrs

6-8hrs

2-3hrs

1-2hrs

XD/08

2-3hrs

9-11hrs

2-3hrs

1-2hrs

XD/10

3-4hrs

9-11hrs

3-4hrs

2-3hrs

XD/12

3-4hrs

11-13hrs

3-4hrs

2-3hrs

Input Material

Tyre, Rubber, Natural Rubber, Rubber

Output: Oil:

45%-50%

Carbon black:

30%-45%

Steel Wire:

10%-15%

Gas:

5%-10%

Land Requirement:

150 sq. Meter with 200 sq. ft shed

ITEM

CONTENT

equipment’s model

XD-06

XD-08

XD-10

Daily Handling capacity

6 tons

8 tons

10 tons

Door's model

Semi-open door

Semi-open door

Semi-open door

Structure Form

Horizontal type

Horizontal type

Horizontal type

Raw material

Waste rubbers/tyres/plastic

Waste rubbers/tyres/plastic

Waste rubbers/tyres/plastic

Material of reactor

Q345R thickness 14mm

Q345R thickness 14mm

Q345R thickness 14mm

Main engine rotating speed

0.8R /min

0.8R /min

0.8R /min

Power

20KW

20KW

20KW

Cooling Mode

Water

Water

Water

Consumption of Cooling water

0.2

0.3

0.4

Heating Mode

Direct

Direct

Direct

Installation

Main engine integral installation

Main engine integral installation

Main engine integral installation

Noise dB (A)

<=85

<=85

<=85

Machine dimension(mm)

D2000*L6000

D2200*L6600

D2600*L6600

Working Mode

Intermittent

Intermittent

Intermittent
