Высококачественная сталь O 1/материал Sk3/стержень из 1,2510 стали

Product Overview

Description

Cold work tool steel 1.2510



Grade:9CrWMn/o1/1.2510/Bo1/SKS3/DF-3



Chemical composition:

Country	Steel NO.	C	Si	Mn	Cr	W	P	S	Other
China GB	9CrWMn	0.85-0.95	≤0.40	0.90-1.20	0.50-0.80	0.50-0.80	≤0.030	≤0.030	—
USA AISI	o1	0.85-0.95	0.20-0.40	1.00-1.30	0.40-0.60	0.40-0.60	—	—	v:0.20
Germany DIN	1.2510	0.90-1.05	0.15-0.35	1.00-1.20	0.50-0.70	0.50-0.70	—	≤0.035	V:0.05-0.15 P≤0.035
Britain	Bo1	0.85-0.95	≤0.40	1.10-1.35	0.40-0.60	0.40-0.60	—	—	Ni≤0.40  V≤0.25
Japan JIS	SK83	0.90-1.00	≤0.35	0.90-1.20	0.50-1.00	0.50-1.00	≤0.030	≤0.030	—
Sweden	DF-3	0.90	0.10	1.20	0.85	0.55	—	—	—



Size

Round	Diameter	Length
	50mm-500mm	2000mm-5800mm
Steel plate	Thickness	Width	Length
	20-400mm	80-1000mm	2000mm-5800mm



Charactteristic:

1.Is an cold working die steel.

2.Wiht highest hardness and abrasion resistance  in the Cr12 and 9SiCr.

3.Low impact toughness,should avoid tempering at about 300°c.

4.should do the resonable structure .



Application:

Make cold stamping die ,gauge and measuring too etc.
