Socks Knitting Machine for Seamless Products

Product Overview

Description



High Lights Of Socks Knitting Machine for Seamless Products



6 shafts E-positive yarn feeding system: Set the yarn feeding parameters through PC touch screen (equipped with the servo motors from Taiwan)



6 guide bars with EL system,2 jacquard bars (equipped with the servo motors from Japanese)



Two sets of sinker device



Double needle bar E24 lath needles



Main motor frequency conversion, CVT



Valid working width: 80”



Standard: Q/HCZZ001-2007



Suitable products:Jacquard seamless tights, shoes fabrics,3D-mesh fabrics.







Technical Specification Of Socks Knitting Machine for Seamless Products



Needle-type: Latch needle



Machine gauge: E24



Products width allowance: 80”



Number of guide bars: 6 guide bars,2 jacquard bars.



Method of warp let-off: E-positive, customized beaming parameters (EBC)



Beam size: 21”



Flange Diameter: φ530



Shaft Diameter: φ210



Aperture: φ152



Beam Width: 530 mm



Density tuning method: Digital controlled, PC touch screen operation



Braiding method: EL



Main shaft speed: 5-500 RPM (frequency control)



Main motor: 3KW



Yarn feeding motor: 1 KW × 6 pieces



Shogging motor: 0.75 KW × 6 pieces



Outline dimension: 4100mm (Length) x 4500 mm (wide) x 3000mm (height)



Total weight: Approximately 4500 Kg
