Our hammer mill is the special milling equipment for materials of < 50 mm (diameter),< 300 mm (length), such as tree trimmings, wood pieces, crop stalks, rice husk, cotton stalk, cottonseed skins and so on. This hammer mill contains some rotors which are mounted by many hammers. The hammers swing following with the rotor at a high speed. And then the materials fed into a feed hopper are shred by the hammers. At last the materials are expelled out and sieved by the exhaust fan and screen.
Application Scope of hammer mill:
The hammer mill machine can be used in producing high quality wood charcoal stick with sawdust, wood chips, branches, crop stalks, sugarcane residue, paddy straw, sunflower stalk, cotton stalks, bamboo dust, palm husk, soybeans husk, tea waste, etc.
1. Wood, tree trunk, tree branch,straw,Bamboo stick etc.
2. Wooden piece, small tree branch,leaf,tree bark ,feedstuff and chemical material etc material
3. Orchard garden , Botanical garden, Landscaping department.(Trimmed branches, trunk, leaf can be crushed as fertilizer .)
4. Machine can installed on the cart or farm vehicle
5. Engine can be electromotor,diesel engine,gasoline engine,both of them are ok for working.
6. Crushing type can be mobile and fixed-line.Can drive by electric motor and diesel engine two- way for choice.
The advantages of hammer mill machine :
1. Low noise.
2. Simple structure, compact arrangement.
3. Competitive price
4. Steady running.
5. Low energy consumption
6. High yield, superior quality finished products and low processing cost.
Hammer Mills | ||||
Model NO. | Power | Output(kg/h) | NW/GW(kgs) | Packing(cm) |
CF158 |
2.2KW/220V 2.2KW/380V | 60-150 | 75/95 |
80*68*59 |
55/75 | ||||
CF198A | 7.5Hp gasoline engine |
150-350 | 120/140 |
68*58*98 |
90/110 | ||||
CF198B |
4KW/380V Electric motor |
150-350 | 120/140 |
68*58*98 |
90/110 | ||||
CF420A(1) |
15 Hp Diesel engine |
350-550 | 360/400 |
147*74*111 |
320/360 | ||||
CF420A(2) |
22 Hp Diesel engine |
400-750 | 360-400 |
147*74*111 |
320-360 | ||||
CF420B(1) |
7.5KW/380V Electric motor |
350-650 | 260/320 |
112*82*107 |
220/280 | ||||
CF420B(2) |
11KW/380V Electric motor |
400-700 | 320/360 |
112*82*107 |
220/280 | ||||
CF500A |
55 Hp Diesel engine |
850-1100 | 800/840 |
150*142*123 |
760/800 | ||||
CF500B | 22KW/380V Electric motor |
800-1100 | 600/630 |
143*62*80 |
560/590 | ||||
