Seamless Elastic Legging Raschel Warp Knitting Machine

Product Overview

Description



High Lights Of Seamless Elastic Legging Raschel Warp Knitting Machine



6 shafts E-positive yarn feeding system: Set the yarn feeding parameters through PC touch screen (equipped with the servo motors from Tai Wan)



10 guide bars with EL system



Two sets of sinker device



Double needle bar 12-18 lath needles (optional)



Main motor frequency conversion, CVT



Valid working width: 130” (3300 mm)



Standard: Q/HCZZ001-2007



Suitable products: Tights, seamless bodywear, medical bandage.





Technical Specification Of Seamless Elastic Legging Raschel Warp Knitting Machine



Needle-type: Latch needle



Machine gauge: E12-E22



Products width allowance: 3300 mm



Number of guide bars: 16 (12 Pattern guide bars)



Method of warp let-off: E-positive, customized beaming parameters (EBC)



Beam size: 21”



Flange Diameter: φ530



Shaft Diameter: φ210



Aperture: φ152



Beam Width: 530 mm



Density tuning method: Digital controlled, PC touch screen operation



Braiding method: EL



Main shaft speed: 5-180 RPM (frequency control)



Main motor: 2.2 KW



Yarn feeding motor: 1 KW × 6 pieces



Shogging motor: 0.75 KW × 16 pieces



Outline dimension: 5100mm (Length) x 2600 mm (wide) x 2800mm (height)



Total weight: Approximately 6500 Kg
