Flake Ice Machine Parameters | ||||||||||||||
Model | Daily Output (T/24h) | Cooling method | Compressor Power | Fan Power for Cooling Tower | Cooling Pump Power | Unit Size (L*W*H mm) | Unit N.W. (KG) | |||||||
BF 500 | 0.5 | Air | 4.1 kw | -- | -- | 1280*800*800 | 160 | |||||||
BF 1000 | 1 | Air | 7.44 kw | -- | -- | 1320*900*900 | 210 | |||||||
BF 2000 | 2 | Air | 10 kw | -- | -- | 1750*1100*1050 | 360 | |||||||
BF 3000 | 3 | Water | 8.45 kw | 0.37 kw | 1.5 kw | 1500**1250*1260 | 1000 | |||||||
BF 5000 | 5 | Water | 13.49 kw | 0.75 kw | 2.2 kw | 1900*1500*1470 | 1100 | |||||||
BF 6000 | 6 | Water | 19.94 kw | 0.75 kw | 2.2 kw | 1900*1500*1470 | 1100 | |||||||
BF 8000 | 8 | Water | 24.2 kw | 1.5 kw | 2.2 kw | 2400*1900*1860 | 1300 | |||||||
BF 10000 | 10 | Water | 33.8 kw | 1.5 kw | 4 kw | 2500*2000*1860 | 1500 | |||||||
BF 15000 | 15 | Water | 44.5 kw | 1.5 kw | 4 kw | 3350*2150*1960 | 3200 | |||||||
BF 20000 | 20 | Water | 64 kw | 1.5 kw | 5.5 kw | 3400*2220*2230 | 4200 | |||||||
BF 25000 | 25 | Water | 76.5 kw | 2.2 kw | 5.5 kw | 3700*2250*2510 | 4600 | |||||||
BF 30000 | 30 | Water | 93.7 kw | 2.2 kw | 7.5 kw | 4700*2250*2520 | 5000 | |||||||
BF 40000 | 40 | Water | 118 kw | 2.2 kw | 7.5 kw | 5000*2300*2700 | 7500 | |||||||
* Compressor brand: Bizter / Hanbell; Refrigerant: R22/R404R. * Power supply: voltage 380 V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately) * Operating conditions: T (water supply):20℃, T (ambient): 32℃, T (condensing): 38℃, T (evaporating): -20℃。 * Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature. * The final interpretation of the above mentioned parameters is in Icesource, there will be no further notice, if there is any technical change. | ||||||||||||||
item | value |
Applicable Industries | Hotels, Food & Beverage Factory, Restaurant, Food Shop, Energy & Mining, Food & Beverage Shops |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Local Service Location | Philippines, Malaysia |
Showroom Location | Philippines, Malaysia |
Condition | New |
Place of Origin | China |
Guangdong | |
Brand Name | CBFI |
Ice Shape | Flake Ice |
Voltage | 380V/50Hz/3Phase or other |
Power | 8.85kw |
Dimension(L*W*H) | 1300*960*1200mm |
Weight | 210kg |
Certification | ce |
Warranty | 1 Year |
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support | |
Key Selling Points | Easy to Operate |
Ice storage capacity | 1000kg |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Marketing Type | Ordinary Product |
Warranty of core components | 1 Year |
Core Components | Pressure vessel, Motor, Other, Bearing, Gear, Pump, Gearbox, Engine, PLC |
Compressor brand | Bitzer / Carrier |
Display | Eletical display |
Electrical components | LG |
Refrigerant | R22/R404a |
Power supply | 380v/50hz/3ph or 220v/60hz/3ph |
Ice shape | Irregular |
Cooling way | Water cooling/Air cooling/Evaporative cooling |
Daily capacity | 0.5 ton to 60 tons |
PLC | Germany Siemens |
